433MHz Antenna | Quarter Wave Helical for RF Modules
433MHz Antenna – Quarter-Wave Helical for Wireless RF
This 433MHz antenna is designed for short-range wireless communication using RF modules. It provides reliable signal transmission and reception for remote controls, IoT sensors, and hobbyist radio projects. The helical design offers a compact yet effective solution with a nominal 2dBi gain, making it ideal for projects where size matters without sacrificing performance. With its 50-ohm impedance, it matches standard RF circuits, minimizing signal loss.
Key Specifications
| Specification | Value |
|---|---|
| Frequency Range | 433 MHz |
| Impedance | 50 ohms |
| VSWR | ≤2.0 |
| Gain | 2 dBi typical |
| Polarization | Linear (vertical) |
| Connector | SMA Male (solderable pin also available) |
| Length | Approximately 170 mm (quarter-wave) |
What You Can Build With This
- 433MHz wireless remote control for lights or fans
- IoT sensor node transmitting temperature/humidity data
- Garage door opener or car remote replacement
- Simple walkie-talkie for learning radio basics
Compatibility
This antenna works with any 433MHz transmitter or receiver module, including popular pairs like FS1000A and XY-MK-5V. It connects via standard SMA jack or can be soldered directly to pads on circuits operating at 3.3V to 12V. Commonly used with Arduino, ESP8266, and Raspberry Pi for wireless data links. The quarter-wave design ensures a balanced radiation pattern in free space.
Wiring Notes
If using the SMA connector, screw it onto a mating SMA jack on your module. For direct solder, the center pin is the signal and the outer ground plane must be connected to circuit ground. Keep the antenna vertical and away from large metal objects for best range. No external matching network is required when used with typical 50Ω modules. For battery-powered projects, consider placing the antenna away from the battery to avoid detuning.
