Emax MT2213 935kV Brushless Motor 1045 Prop Set CCW Red Cap
Emax MT2213 935kV Brushless Drone Motor with 1045 Propeller Set CCW - Red Cap
The Emax MT2213 is a 935KV brushless outrunner motor designed for quadcopters and fixed-wing drones. It delivers efficient thrust with 1045 propellers on 3S or 4S LiPo packs. The CCW thread and red anodized cap make it easy to identify and match with a CW counterpart.
Key Specifications
| Specification | Value |
|---|---|
| Motor Model | MT2213 |
| KV Rating | 935 RPM/V |
| Stator Size | 22mm x 13mm |
| Configuration | 12N14P |
| Max Thrust (3S, 1045) | ~750g per motor |
| Weight (Motor Only) | ~56g |
What You Can Build With This
- Quadcopter with a 450mm frame and 3S battery
- FPV freestyle quad on 4S with 1045 props
- Fixed-wing UAV in pusher configuration
- Tricopter with a yaw mechanism for stable flight
Compatibility
Pairs well with 30A SimonK or BLHeli ESCs and flight controllers like Pixhawk, Naze32, or CC3D. The 1045 propellers included suit frames with at least 250mm diagonal motor spacing. Use 3S 2200–4000mAh or 4S 1500–2200mAh batteries. The 16x19mm mounting pattern fits most carbon fiber and glass fiber arms.
Wiring Notes
Solder the three motor wires to your ESC in any order; swap any two to reverse direction. Ensure the propeller nut tightens counterclockwise to match the CCW thread. Keep peak current below 12A per motor.
Why Buy from Compoden
Every component is sourced from verified suppliers and tested for compatibility before listing. We've spent 10 years building projects for makers, schools, and institutions across India. Ships from Bengaluru in 3-5 days. If defective on arrival, replace within 7 days.
Is this compatible with 4S LiPo batteries?
Yes, the MT2213 can handle 4S with 1045 props, but throttle management is recommended to stay below the 12A continuous rating and prevent overheating.
Does this motor come with propellers?
Yes, the set includes two CCW 1045 propellers with the matching red cap.
What frame size is this motor designed for?
The 2213 stator is best suited for 450mm class quadcopter frames. It is too large and heavy for 250mm racing frames.
