HX1230 96x68 Graphic LCD Display Module
Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts
HX1230 96x68 Graphic LCD Display Module
A monochrome 96x68 pixel graphic LCD driven by the HX1230 controller over a serial bus, often used as a higher-resolution alternative to the Nokia 5110. It needs only four I/O pins and includes an LED backlight.
Specifications
- 96x68 pixel monochrome graphic
- HX1230 controller
- 2.7-5V supply
- Serial bus interface up to 4 Mbit/s
- 4 I/O pins
- LED backlight
- PCB 4.5 x 4.6 cm
Compatible with
- Arduino
- Microcontrollers with SPI or serial interface
- 2.7-5V systems
Build it with Compoden's AI
Tell Compoden's AI build assistant what you want to display and it picks a compatible screen, checks it against your board's interface and voltage, and hands you the wiring and the driver code matched to the exact module - all from real in-stock parts.
Built and Backed by Compoden
We have spent 10 years supplying displays, boards, and parts to makers, schools, and engineering teams across India. Every Compoden order includes our AI build companion to help you wire the screen and write the driver code.
What is the resolution?
96x68 pixels, monochrome.
How many pins does it need?
Four I/O pins over a serial bus interface.
What supply voltage?
2.7V to 5V.
Ask Soldr above what you can build with this — it knows every Compoden kit this part appears in.
