3.7V 600mAh 30C LiPo Battery (YY802535) for Drones
3.7V 30C 600mAh Lithium-Polymer Rechargeable Battery (YY802535) for Drones
This 1S 3.7V lithium-polymer battery provides a 600mAh capacity with a 30C continuous discharge rate, suitable for micro drones and small DIY electronics. Its 8×25×35mm footprint fits compact frames, and the high 18A burst capability handles sudden throttle changes in flight.
Key Specifications
| Specification | Value |
|---|---|
| Nominal Voltage | 3.7V (1S) |
| Capacity | 600mAh |
| Discharge Rate | 30C continuous (18A) |
| Dimensions (T×W×L) | 8mm × 25mm × 35mm |
| Weight | Approx. 14g |
| Connector | JST-PH 2.0mm |
What You Can Build With This
- Micro FPV quadcopter or Tiny Whoop-style drone
- Small line-following or obstacle-avoidance robot
- Portable USB power bank for wearables using a boost converter
- Mini RC crawler or hovercraft with brushed motor setup
Compatibility
This battery works directly with 1S flight controllers found on 65mm–75mm micro drones (e.g., Eachine E010, BetaFPV Lite). The JST-PH 2.0mm connector mates with most micro brushed and brushless whoop boards. It pairs with any 1S LiPo charger supporting JST input. Voltage matches standard 3.7V Arduino modules and single-cell ESP32 projects.
Wiring Notes
The red wire is positive, black is ground. Solder or plug into a board with matching JST 2.0mm socket. Do not draw more than 18A continuously, and never reverse polarity—the cell will swell and pose a fire risk.
Why Buy from Compoden
Every component is sourced from verified suppliers and tested for compatibility before listing. We've spent 10 years building projects for makers, schools, and institutions across India. Ships from Bengaluru in 3-5 days. If defective on arrival, replace within 7 days.
Is this compatible with a 2S charger?
No, this is a single-cell (1S) battery. Using a 2S charger would overcharge and damage the cell. Use only a 1S LiPo charger with JST-PH connector.
How long does it take to charge?
With a standard 1S 500mA USB charger, expect around 80 minutes from full discharge. Charging at 1C (600mA) takes roughly 60 minutes.
Can I fly a 2-inch cinewhoop with this?
This battery is too small for a 2-inch setup; those typically need 2S–3S 450–650mAh. It’s best for micro drones under 75mm frame size.
