Arduino Nano IMU Calibration Kit for Industrial Boiler Monitoring v6
Industrial Boiler Temperature Monitor Kit - Arduino Nano IMU Calibration & Validation
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-5 days.
This advanced kit enables you to build a precision temperature monitoring system for industrial boilers, characterizing the BMI088 6-axis MEMS IMU across varying thermal conditions. You'll calibrate orientation data against a reference platform, validating sensor fusion algorithms that mirror real-world process control scenarios in power plants and refineries.
What You'll Build
You'll assemble a diagnostic tool that simulates boiler shell monitoring, mapping IMU orientation at controlled tilt angles while logging temperature and pressure. The system displays real-time data on the 0.96-inch OLED, producing calibration curves that quantify the BMI088's thermal drift behavior-a critical skill for instrumentation engineers working on condition-based maintenance.
What You'll Learn
- Characterize MEMS accelerometer and gyroscope outputs under temperature gradients
- Calibrate IMU orientation using a precision tilt platform and reference angles
- Interface multiple I2C sensors (BMI088, BMP390, DS18B20) with Arduino Nano
- Validate sensor fusion data for industrial IoT applications
Kit Contents
| Component | Quantity |
|---|---|
| Arduino Nano | 1 |
| BMI088 IMU | 1 |
| BMP390 Pressure | 1 |
| DS18B20 | 1 |
| 0.96in OLED | 1 |
| Precision Tilt Platform | 1 |
| MiniUSB Cable | 1 |
| Half Breadboard | 1 |
| M-M Wires | 20 |
Why Buy This Kit Instead of Sourcing Parts Separately
| Factor | Sourcing Separately | Compoden Kit |
|---|---|---|
| Compatibility checks | You verify every part | Pre-tested as a system |
| Build support | Forums and scattered tutorials | AI companion trained on this exact project |
| Time to first working build | Days of debugging | Hours, with step-by-step guidance |
| Shipping coordination | Multiple sellers, multiple delays | One shipment from Bengaluru in 3-5 days |
Who This Kit Is For
This kit is tailored for B.Tech ECE and EEE students tackling industrial instrumentation labs, Smart India Hackathon participants building boiler health monitors, and ATL Tinkering Lab mentors guiding advanced sensor calibration. It also serves IIT/NIT/VIT/BITS researchers prototyping MEMS validation setups for thermal drift studies.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project - accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
Scan the QR code to start the AI companion, or reach us on WhatsApp with photos of your setup. We'll guide you through wiring, code, and calibration steps.
Can I use this kit for a final-year B.Tech project?
Absolutely-it's designed for industrial instrumentation projects and can be extended with data logging to a PC or cloud platform for a full thesis demonstration.
Do I need an external power supply?
The kit runs entirely via the included MiniUSB cable; the Arduino Nano powers all sensors, so no extra adapter is required.
How accurate is the tilt platform for calibration?
The precision tilt platform provides reproducible angular steps within 0.5�, enabling reliable calibration data for validating IMU orientation algorithms.
