ATL Wind Speed Anemometer Kit — a beginner-level kit.
ATL Wind Speed Anemometer Kit – Build a Real-Time Wind Speed Meter with Arduino
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.
You've probably felt the wind push against you and wondered how fast it's moving. With this kit, you won't just guess — you'll build a precise instrument that measures wind speed in kilometers per hour and displays it on a bright OLED screen. It turns a simple classroom physics concept into a working tool you can hold in your hand, perfect for weather stations, science fairs, and ATL lab experiments.
What You'll Build
A handheld or mountable anemometer that uses a spinning 3-cup rotor and a Hall effect sensor to detect every rotation. An Arduino Nano counts the pulses, converts them into engineering units, and shows the live wind speed on a crisp 0.96-inch OLED display. By the end, you'll have a functional weather instrument that demonstrates the direct link between magnetic field detection, microcontroller programming, and real-world environmental monitoring.
What You'll Learn
- How a Hall effect sensor detects magnetic fields and generates digital pulses without physical contact
- Programming an Arduino to count sensor interrupts and avoid missing fast rotations
- Converting rotational data into meaningful speed units like km/h using calibration formulas
- Wiring and integrating multiple components — sensor, display, and microcontroller — on a breadboard reliably
Kit Contents
| Component | Quantity |
|---|---|
| Arduino Nano | x1 |
| Hall Effect Sensor | x1 |
| Neodymium Magnet | x1 |
| 3-Cup Anemometer | x1 |
| 0.96in OLED | x1 |
| Half Breadboard | x1 |
| MiniUSB Cable | x1 |
| M-M Wires | x15 |
Who This Kit Is For
ATL Tinkering Lab students exploring sensor-based measurement will find this kit directly relevant to curriculum goals around environmental sensing and data acquisition. CBSE physics students can use it to connect textbook concepts of rotational motion and magnetism to a working prototype. Teachers running STEM clubs, B.Tech ECE/EEE undergraduates building mini-projects, and Smart India Hackathon participants looking for a reliable weather sensing module will all get a fully compatible, no-soldering-required build experience.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
Scan the QR code on the box to start a conversation with our AI companion trained on this exact anemometer project, or reach out via WhatsApp — you're never stuck alone.
Does this kit need actual wind, or can I test it indoors?
You can spin the 3-cup rotor by hand or place it in front of a table fan indoors — the Hall effect sensor will count every rotation and display the speed, letting you test and calibrate without waiting for a windy day.
Is any soldering or special tools required?
None at all. All connections use jumper wires and a half breadboard, so you can prototype, tweak, and reassemble without touching a soldering iron.
Can I log the wind speed data for a science fair or ATL project report?
Yes. The Arduino Nano can transmit serial data to a computer, and with a slight firmware extension, you can log wind speed readings over time for graphical analysis and presentation.
Hall effect sensor counts rotations of a 3-cup anemometer — Arduino calculates and displays wind speed in km/h.
What's in this kit
- Arduino Nano
- Hall Effect Sensor
- Neodymium Magnet
- 3-Cup Anemometer
- 0.96in OLED
- Half Breadboard
- MiniUSB Cable
- M-M Wires x15
