ESP32-S3 Neural Style Audio FX Kit with ESP32
ESP32-S3 Neural Audio FX Kit: Build a Real-Time Convolution Reverb Processor on ESP32
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-5 days.
This kit transforms audio in real time by applying room impulse response convolution reverb directly on the ESP32-S3's vector processing unit. You'll capture 16kHz audio from the INMP441 I2S microphone, run optimized convolution filter weights, and hear spatially-rich reverb through the amplified speaker. Perfect for audio engineers, DSP enthusiasts, and engineering students wanting to implement professional audio effects on a microcontroller.
What You'll Build
You'll assemble a portable neural audio effects unit that captures sound through an I2S MEMS microphone, processes it using convolutional reverb algorithms accelerated on the ESP32-S3's SIMD vector unit, and outputs studio-quality audio through a 3W speaker. The build includes soldering the custom analog circuit, integrating the MCP4725 DAC and PAM8403 amplifier, and calibrating real-time filter coefficients for different room impulse responses. This is a full signal chain from acoustic capture to processed playback.
What You'll Learn
- Real-time I2S audio input/output configuration on ESP32-S3
- Implementation of time-domain convolution filtering using vector instructions
- Designing low-noise analog audio circuits with DAC and amplifier
- Optimizing DSP algorithms for embedded microcontrollers
Kit Contents
| Component | Quantity |
|---|---|
| ESP32-S3 Dev Board | 1 |
| INMP441 I2S Mic | 1 |
| MCP4725 DAC | 1 |
| PAM8403 Amp | 1 |
| 3W 8Ω Speaker | 1 |
| 4.7kΩ Resistors | 5 |
| 100nF Caps | 10 |
| PCB Prototype Board | 2 |
| 5V 2A PSU | 1 |
| Soldering Iron | 1 |
| Solder Wire | 1 |
Why Buy This Kit Instead of Sourcing Parts Separately
| Factor | Sourcing Separately | Compoden Kit |
|---|---|---|
| Compatibility checks | You verify every part | Pre-tested as a system |
| Build support | Forums and scattered tutorials | AI companion trained on this exact project |
| Time to first working build | Days of debugging | Hours, with step-by-step guidance |
| Shipping coordination | Multiple sellers, multiple delays | One shipment from Bengaluru in 3-5 days |
Who This Kit Is For
This kit is designed for B.Tech ECE/EEE students tackling audio DSP coursework, participants in Smart India Hackathon looking for a hardware-audio prototype, and engineering undergraduates at IITs, NITs, VIT, BITS, and other institutions who want hands-on experience with real-time convolution reverb. It also suits electronics hobbyists building a portable vocal or guitar effects unit.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR
INMP441 audio sampled at 16kHz. Convolution filter weights implement room impulse response reverb on S3 vector unit.
