Pi 5 Power Grid Frequency Monitor
Raspberry Pi 5 Power Grid Frequency Monitor Kit — AI-Powered Grid Stability Analyzer
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-5 days.
Transform a Raspberry Pi 5 into a high-speed power grid frequency monitor that samples AC line signals at 10 kHz. Using the precision ADS8688 ADC and a safe voltage transformer, you’ll capture micro-fluctuations in grid frequency, then train and deploy an on-device ML model to classify events like under-frequency load shedding or cyber‑attack signatures. Perfect for understanding India's grid dynamics or building a Smart India Hackathon prototype.
What You'll Build
A real‑time monitoring system that logs every grid frequency cycle to an NVMe SSD, processes data with Python, and triggers alerts when anomalous events occur. The system runs entirely on the Pi 5, so you can deploy it in a dorm room, lab, or as a standalone IoT node that streams stability metrics to a dashboard.
What You'll Learn
- High-speed analog signal acquisition using the ADS8688 16‑bit ADC at 10 ksps
- Feature engineering from raw frequency waveforms (zero‑crossing, RMS, harmonic distortion)
- Training a lightweight ML model (Random Forest or TinyML) for grid event classification
- Deploying an edge AI pipeline on Raspberry Pi 5 with NVMe storage for continuous logging
Kit Contents
| Component | Quantity |
|---|---|
| Raspberry Pi 5 4GB | 1 |
| ADS8688 ADC | 1 |
| Voltage Transformer | 1 |
| NVMe SSD 256GB | 1 |
| Pi 5 M.2 HAT+ | 1 |
| USB-C PSU | 1 |
| M-M Wires | 15 |
Why Buy This Kit Instead of Sourcing Parts Separately
| Factor | Sourcing Separately | Compoden Kit |
|---|---|---|
| Compatibility checks | You verify every part | Pre-tested as a system |
| Build support | Forums and scattered tutorials | AI companion trained on this exact project |
| Time to first working build | Days of debugging | Hours, with step-by-step guidance |
| Shipping coordination | Multiple sellers, multiple delays | One shipment from Bengaluru in 3-5 days |
Who This Kit Is For
This kit is designed for intermediate makers aged 15–21 with basic Python and electronics exposure. It fits into CBSE Class 12 physics models on AC mains stability, B.Tech ECE/EEE capstone projects on power quality monitoring, and Smart India Hackathon teams prototyping IoT‑based grid health solutions. Students at IITs, NITs, VIT, and BITS will find it accelerates their ML‑on‑the‑edge coursework.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
Scan the QR code on the box to access the AI companion trained on this exact project. It provides step‑by‑step guidance for wiring, software setup, and ML training. For additional help, message us on WhatsApp.
Do I need an oscilloscope to verify the signal?
No. The kit includes a pre‑characterized voltage transformer and the AI companion validates ADC output visually. A basic multimeter can confirm the transformer’s secondary voltage if desired, but it is not required.
Can I use this kit to monitor Indian grid frequency specifically?
Yes. The voltage transformer steps down 230V AC to a safe low‑voltage signal tuned for 50 Hz nominal frequency — perfect for Indian grids. The ML model can be trained on local frequency event patterns common in Indian substations.
What machine learning skills are needed?
Basic Python is recommended. The AI companion includes a pre‑written Jupyter notebook that walks you through feature extraction and model training with scikit‑learn. You’ll learn the ML workflow even if you’re new to classification algorithms.
Grid frequency sampled at 10kHz by Pi 5 ADC — ML model detects frequency events and classifies grid stability state.
