Pi 5 Smart Meter Fraud Detection
Pi 5 Smart Meter Fraud Detection Kit – Uncover Anomalies Across 3 Meter Profiles
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-5 days.
Electricity theft through meter bypass or tampering drains utility revenues across India. This kit turns a Raspberry Pi 5 into a portable field unit that clamps onto three adjacent meters, samples their power draw with non‑invasive CT sensors, and flags consumption anomalies by comparing real‑time profiles — all on‑device, without cloud dependency.
What You'll Build
A self‑contained anomaly detector that captures high‑resolution current waveforms from three neighbouring meters, stores them to the NVMe SSD via the M.2 HAT, and runs a lightweight pattern‑matching algorithm on the Pi 5. You’ll see suspicious dips, sudden spikes, or mismatched load patterns that suggest tampering, and log events for later audit.
What You'll Learn
- Interface non‑invasive SCT‑013 CT sensors with a 16‑bit ADC to capture sub‑ampere current detail.
- Stream and timestamp multi‑sensor data at over 800 samples per second onto NVMe storage.
- Implement a rolling‑window anomaly detection model that compares meter profiles in near‑real time.
- Cross‑correlate load signatures between three meters to expose tampering patterns not visible on a single trace.
Kit Contents
| Component | Quantity |
|---|---|
| Raspberry Pi 5 4GB | 1 |
| SCT-013 CT Sensor | 3 |
| ADS1115 ADC | 1 |
| NVMe SSD 128GB | 1 |
| Pi 5 M.2 HAT+ | 1 |
| USB-C PSU | 1 |
| M-M Wires | 15 |
Why Buy This Kit Instead of Sourcing Parts Separately
| Factor | Sourcing Separately | Compoden Kit |
|---|---|---|
| Compatibility checks | You verify every part | Pre-tested as a system |
| Build support | Forums and scattered tutorials | AI companion trained on this exact project |
| Time to first working build | Days of debugging | Hours, with step-by-step guidance |
| Shipping coordination | Multiple sellers, multiple delays | One shipment from Bengaluru in 3-5 days |
Who This Kit Is For
CBSE Class 11‑12 students exploring AI‑IoT in their final project, B.Tech ECE/EEE undergraduates prototyping for Smart India Hackathon, and ATL Tinkering Lab mentors who want a ready‑to‑assemble energy monitoring use‑case. It also fits the capstone trajectory of IIT, NIT, VIT, and BITS Pilani learners working on smart grid analytics.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
Scan the QR code inside the box to open the AI companion trained on this Pi 5 fraud detection project. The companion can walk you through each connection and line of code; if you need human help, message us on WhatsApp and we’ll respond within an hour.
Do I need a real electricity meter to test the detection?
No. You can simulate consumption patterns using common household loads (hair dryer, iron, LED bulbs) and the guide shows how to create realistic test signatures. The CT sensors clamp onto any single‑phase wire, so a bench setup works perfectly.
Can this kit work with a 3‑phase supply?
The three CT sensors monitor up to three single‑phase lines. For true 3‑phase power measurement you would need a voltage reference, but this kit focuses on relative load comparison between meters, which is effective on single‑phase distribution networks commonly used in residential Indian metering.
Is programming experience required to complete the project?
The included Python scripts are heavily commented and the AI companion explains each block. If you’ve written a few lines of Python before, you’ll move quickly. Even with zero code background, the step‑by‑step commentary gets you a working detector by the end of the build session.
Consumption pattern anomaly detection on Pi 5 identifies electricity theft by comparing neighbouring meter profiles.
What's in this kit
- Raspberry Pi 5 4GB
- SCT-013 CT Sensor x3
- ADS1115 ADC
- NVMe SSD 128GB
- Pi 5 M.2 HAT+
- USB-C PSU
- M-M Wires x15
