Home › 10F Supercapacitor - 2.7V Ultracapacitor for Backup Power
10F Supercapacitor - 2.7V Ultracapacitor for Backup Power - Compoden
In Stock

10F Supercapacitor - 2.7V Ultracapacitor for Backup Power

SKU: CDN-0884 Brand: Compoden Category: Electronics > Electronic Components
Rs. 350.00
Inclusive of all taxes
Free Shipping on prepaid orders above ₹1,999
Ships in 3-7 days
7-Day Warranty on manufacturing defects
GST invoice 18% GST included · HSN 85322900
Pay with UPI Cards Netbanking Cash on Delivery
Need 10+ units? Contact us for bulk pricing
100% Genuine Products
Expert Technical Support
Quality Tested
Soldr.ai Ask about this product

Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts

10F Supercapacitor — 2.7V Ultracapacitor for Reliable Energy Storage

This 10 Farad supercapacitor offers massive capacitance in a compact cylindrical package for short-term energy storage. Use it for real-time clock backup, solar-powered circuits, or to buffer peak current in battery-less designs. Its low internal resistance ensures efficient charge/discharge cycles, making it a durable alternative to small batteries in many applications.

Key Specifications

Specification Value
Capacitance 10 Farads
Rated Voltage 2.7 V DC
ESR <30 mΩ
Operating Temperature -40°C to +85°C
Leakage Current <0.5 mA after 72h
Dimensions 10 mm × 30 mm (approx.)

What You Can Build With This

  • RTC or SRAM power backup for microcontrollers
  • Solar garden light or IoT sensor node power buffer
  • Motor driver surge current supply to protect lithium cells
  • DIY spot welder capacitor bank (use appropriate balancing circuit)

Compatibility

This 2.7V supercapacitor interfaces with any circuit that stays below its maximum voltage. It pairs with low-voltage boards like ESP8266 or Arduino (with a regulator) for backup power, or with boost converters to step up voltage. For higher voltage systems, place multiple units in series with balancing resistors.

Wiring Notes

Observe polarity: the longer lead is positive. Never apply reverse voltage. When charging from a constant current source, keep current below 500 mA unless specified. For series banks, add a voltage divider or active balancing IC to prevent overvoltage on individual cells.

Is this compatible with Arduino Uno?

Yes, but its 2.7V maximum is below the 5V logic level. Never charge it with a TP4056 or any 4.2 V Li-ion charger; it is rated 2.7 V. Charge from 5 V through a series resistor with a 2.7 V limit (e.g. a 2.5-2.7 V regulator or a supercapacitor charger IC), and use a boost converter to power the Arduino from it.

How do I charge this supercapacitor safely?

Use a dedicated supercapacitor charger IC or a simple series resistor; never a 4.2 V Li-ion charger such as the TP4056 or BQ24210. For a 5V source, start with a 10Ω resistor and monitor voltage until it reaches 2.5V, then disconnect.

Can I replace a coin cell with this capacitor?

Absolutely. It provides far more cycles than a CR2032 and can be recharged thousands of times. Just ensure your circuit can run down to 2.7V and you add a charging path.

Free Setup Handoff Document Included

Every Compoden order includes a free setup handoff document — step-by-step instructions to get your component working within minutes. Download it via QR code on your package. The handoff document is also trained to help you troubleshoot the majority of problems.
