4 Channel Relay & Opto-Isolated Input Board
This board integrates four 10A SPDT relays and four independent opto-isolated digital inputs on a single PCB. It safely links low‑voltage microcontrollers to high‑power AC or DC devices while the optocouplers protect your controller from ground loops and voltage spikes. Ideal for appliance control, machine sensing, and automation projects.
Key Specifications
| Specification | Value |
|---|---|
| Relay Channels | 4 (each SPDT – NO, COM, NC) |
| Relay Coil Voltage | 5V DC |
| Max Switching Load | 10A @ 250VAC / 10A @ 30VDC |
| Opto‑Isolated Input Channels | 4 (on‑board LED indicators) |
| Input Signal Voltage | 3V – 24V DC (optocoupler active) |
What You Can Build With This
- Home appliance scheduler – turn lights, fans, or heaters on/off from a smartphone
- Automated greenhouse – control water pumps and read soil‑moisture sensors simultaneously
- Garage door opener with limit‑switch feedback for fully automatic operation
- Industrial status panel – monitor machine sensors (proximity, push‑buttons) and trigger alarms or relays
Compatibility
Designed for any 3.3V or 5V controller pin – works directly with Arduino Nano, Uno,
