Flow-Based Smart Home Kit: Raspberry Pi 4, DHT22, 4 Relays
Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts
Flow-Based Smart Home Kit: Raspberry Pi 4, DHT22, 4 Relays — an intermediate-level kit.
Flow-Based Smart Home Kit: Raspberry Pi 4, DHT22, 4 Relays
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.
Kit at a glance
What you build: A flow-based smart home: a Raspberry Pi 4 runs a visual, drag-and-drop flow programming tool that reads a DHT22 and switches four relays, so you build home automation rules by wiring blocks together, then control it from a phone dashboard.
What's in the box
- Raspberry Pi 4 Model B 2GB
- DHT22
- 4-ch Relay Module
- 1N4007 Diode × 5
- 4.7kΩ Resistors × 5
- 40-pin GPIO Header
- M-F Wires × 20
- MicroSD Card 32GB
- USB-C PSU
Power: USB-C power supply included.
Skill level: Intermediate (4-5 hours).
Frequently asked questions
Do I need to write code?
Very little: you connect blocks in a browser.
Can it switch mains devices?
The relays can, but mains wiring needs a qualified person.
Turn your living space into a smart home controlled right from your mobile browser. This kit walks you through installing a flow-based dashboard tool on a Raspberry Pi 4, wiring a DHT22 temperature-humidity sensor and a 4-channel relay module, and building a flow-based dashboard that toggles appliances and displays sensor readings over WiFi. No cloud subscription needed — everything runs on your local network.
What You'll Build
A fully functional a flow-based dashboard tool dashboard on Raspberry Pi 4 that lets you switch lights, fans, or other appliances on and off while viewing real-time temperature and humidity — all from your phone’s browser, without any coding required on the client side. The dashboard updates instantly and can be styled with buttons, gauges, and charts.
What You'll Learn
- Install and configure a flow-based dashboard tool on Raspberry Pi 4
- Read DHT22 sensor data via Python or a flow-based dashboard tool GPIO nodes
- Control a 4-channel relay module safely using flyback diodes
- Design a responsive web dashboard accessible over local WiFi
Kit Contents
| Component | Quantity |
|---|---|
| Raspberry Pi 4 Model B 2GB | 1 |
| DHT22 | 1 |
| 4-ch Relay Module | 1 |
| 1N4007 Diode | 5 |
| 4.7kΩ Resistors | 5 |
| 40-pin GPIO Header | 1 |
| M-F Wires | 20 |
| MicroSD Card 32GB | 1 |
| USB-C PSU | 1 |
Who This Kit Is For
Perfect for CBSE students building a smart home automation project for practical exams, B.Tech ECE/EEE students prototyping an IoT-based home control system, ATL Tinkering Lab innovators, and Smart India Hackathon participants looking for a ready-to-go IoT kit that teaches a flow-based dashboard tool and dashboard design.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR
Pi 4 a flow-based dashboard tool dashboard controls GPIO relays and reads DHT22. Accessible from phone on local WiFi.
