Arduino Thrust Vectoring Simulation Kit - Build a Joystick-Controlled Rocket Gimbal
Simulated Thrust Vectoring Kit with Arduino Uno + Servo: Build a Joystick-Controlled Rocket Gimbal
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-5 days.
Steer a model rocket nozzle using nothing but a joystick. This kit puts thrust vectoring—the same technology that steers ISRO’s PSLV and GSLV—right on your workbench. Move the joystick left, and one servo pitches the gimbal; push forward, and both servos deflect a simulated engine bell. Within three hours, you’ll have a working demo that visually explains how rockets change direction in space.
What You'll Build
A two-axis servo gimbal that replicates rocket nozzle TVC deflection. The dual-axis joystick acts as your flight controller: one servo handles pitch, the other handles yaw. Attach a paper cone or 3D-printed nozzle to the gimbal, and watch it tilt as you “fly” the rocket. It’s a tabletop simulation that makes aerospace engineering tangible.
What You'll Learn
- Controlling SG90 servos with PWM signals from Arduino Uno
- Reading dual-axis joystick analog values and mapping them to servo angles
- Translating mechanical joystick movements into simulated rocket steering
- Assembling circuits on a breadboard without soldering—perfect for young makers
Kit Contents
| Component | Quantity |
|---|---|
| Arduino Uno R3 | 1 |
| Dual-Axis Joystick | 1 |
| SG90 Servo | 2 |
| 10kΩ Resistors | 5 |
| 100nF Capacitors | 5 |
| 400-pt Breadboard | 1 |
| M-M Wires | 20 |
| 9V Battery Snap | 1 |
Why Buy This Kit Instead of Sourcing Parts Separately
| Factor | Sourcing Separately | Compoden Kit |
|---|---|---|
| Compatibility checks | You verify every part | Pre-tested as a system |
| Build support | Forums and scattered tutorials | AI companion trained on this exact project |
| Time to first working build | Days of debugging | Hours, with step-by-step guidance |
| Shipping coordination | Multiple sellers, multiple delays | One shipment from Bengaluru in 3-5 days |
Who This Kit Is For
Designed for CBSE Class 6–10 students exploring robotics, ATL Tinkering Lab mentors, and young space enthusiasts aged 5–15. It’s also a great mini-project for first-year B.Tech students (ECE/EEE) who need a hands-on introduction to actuators and sensor integration. Smart India Hackathon participants will find it a quick prototyping base for rocket control systems.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We’ve spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
Scan the QR code inside your kit to talk to the AI companion, or send us a photo on WhatsApp. We’ll guide you step-by-step until your gimbal moves with the joystick.
Does the kit include a physical rocket nozzle model?
No, the kit provides the electronic gimbal system. You can attach a paper cone, a 3D-printed nozzle, or even a small LED light to visualise the deflection. The coding and circuit skills remain the focus.
Can I use this for a science fair or school exhibition?
Absolutely. The demo shows real thrust vectoring principles used in ISRO and SpaceX rockets. Many students have used similar setups for CBSE National Science Exhibition and ATL marathon events.
What if the servo behaves erratically?
Most issues trace back to power supply or loose breadboard connections. Our AI companion will help you isolate the problem; if the servo is faulty, we’ll ship a replacement under the 7-day defect policy.
Joystick input controls two servo gimbals that visually simulate a rocket nozzle TVC deflection.
What's in this kit
- Arduino Uno R3
- Dual-Axis Joystick
- SG90 Servo x2
- 10kΩ Resistors x5
- 100nF Caps x5
- 400-pt Breadboard
- M-M Wires x20
- 9V Battery Snap
