AS3935 Lightning Detection Kit Kit with Arduino Uno + Sensor
Build a Personal Storm Early Warning System with the AS3935 Lightning Detection Kit & Arduino Uno
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-5 days.
Ever been caught off-guard by a sudden thunderstorm while playing cricket, hiking, or running outdoor equipment? This kit lets you build a real-time lightning detection station that warns you before a storm hits. The AS3935 sensor hears the electromagnetic signature of lightning up to 40 km away, classifies the strike's distance, and displays an immediate alert on the OLED – giving you minutes of advance notice.
What You'll Build
A compact, Arduino-powered device that continuously monitors for lightning activity and displays storm proximity on a bright OLED screen. When the AS3935 detects a strike, the system calculates how far away it is – from right overhead to 40 km – and shows a clear warning: "Storm Approaching!" You'll have a functional personal weather safety tool you can set up on your desk or carry outdoors.
What You'll Learn
- How lightning detection works: AS3935 sensor's RF signal analysis and strike distance estimation
- SPI communication between the AS3935 module and Arduino Uno
- Driving a 0.96-inch OLED display to show real-time alerts and storm data
- Implementing a storm alert algorithm that filters noise and classifies lightning distance into actionable warnings
Kit Contents
| Component | Quantity |
|---|---|
| Arduino Uno R3 | 1 |
| AS3935 Lightning Sensor | 1 |
| 0.96in OLED Display | 1 |
| 4.7kΩ Resistors | 5 |
| 100nF Capacitors | 5 |
| 400-pt Breadboard | 1 |
| Male-to-Male Jumper Wires | 20 |
| Male-to-Female Jumper Wires | 10 |
| 9V Battery Snap | 1 |
Why Buy This Kit Instead of Sourcing Parts Separately
| Factor | Sourcing Separately | Compoden Kit |
|---|---|---|
| Compatibility checks | You verify every part | Pre-tested as a system |
| Build support | Forums and scattered tutorials | AI companion trained on this exact project |
| Time to first working build | Days of debugging | Hours, with step-by-step guidance |
| Shipping coordination | Multiple sellers, multiple delays | One shipment from Bengaluru in 3-5 days |
Who This Kit Is For
Perfect for CBSE Class 11-12 students exploring atmospheric physics in a practical project, B.Tech ECE/EEE undergraduates tackling sensor integration assignments, and Smart India Hackathon teams prototyping weather alert IoT devices. Also ideal for ATL Tinkering Labs demonstrating real-world environmental sensing.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
Scan the QR code to access your AI companion, which knows every step of this exact project. You can also reach our engineers on WhatsApp for direct guidance.
How accurate is the lightning distance measurement?
The AS3935 estimates strike distance within roughly ±1–3 km for strikes up to 40 km away, providing reliable early warnings to take shelter or disconnect sensitive electronics.
Can I use this kit outdoors during a storm?
The sensor itself must remain indoors or in a protected enclosure to avoid rain damage. Place the assembled kit near a window to detect lightning safely while staying dry.
What if no lightning is detected for days?
The AS3935 continuously monitors and can be tested using its built-in disturbance detection mode, which simulates lightning-like events so you can verify your build at any time.
AS3935 detects lightning strikes up to 40km away and classifies distance. OLED shows storm approaching alert.
What's in this kit
- Arduino Uno R3
- AS3935 Lightning Sensor
- 0.96in OLED
- 4.7kΩ Resistors x5
- 100nF Caps x5
- 400-pt Breadboard
- M-M Wires x20
- M-F Wires x10
- 9V Battery Snap
