Colour Sensor Fruit Sorter Kit — a beginner-level build.
Build a Colour-Sorting Machine with Arduino Uno, a TCS34725 Colour Sensor and Two Servos
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.
Feed small objects past a colour sensor and watch a servo send each one left or right by colour: red tomatoes one way, green ones the other, or sweets and beads by shade. The TCS34725 reads red, green and blue light, and the Arduino Uno decides where each item goes.
What You'll Build
You wire the TCS34725 module to the Uno's I2C pins and two SG90 servos to PWM pins on the breadboard. One servo releases items one at a time onto the sensor, and the other moves a flap to the right bin. You build the chute and bins from card, and the sketch reads each item's colour, compares it with saved samples and sorts it.
What You'll Learn
- Reading red, green and blue values from a TCS34725 over I2C
- Teaching the code a colour by saving sample readings
- Moving two SG90 servos in a timed sequence
- Building a simple feeder and sorting flap
Kit Contents
| Component | Quantity |
|---|---|
| Arduino Uno R3 CH340G | 1 |
| TCS34725 RGB Color Sensor Module with IR Filter | 1 |
| SG90 9g Micro Servo Motor | 2 |
| 400-point solderless breadboard | 1 |
| Dupont Jumper Wire Kit (M-M, M-F, F-F, 20cm, 22AWG) | 1 |
Who This Kit Is For
Beginners who want a moving, hands-on project, and anyone curious about how sorting machines in factories and farms make decisions.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
Do I need to build the chute?
Yes. Make the chute, feeder and bins from card or plastic. The kit supplies the electronics and servos.
Why use a sensor with an IR filter?
The filter blocks infrared light, so readings match the colours you see more closely.
Why do readings change with room light?
Ambient light adds to the reading. Shade the sensor and use its built-in LED for steady results.
Arduino Uno colour sorter: a TCS34725 colour sensor reads each item and two SG90 servos feed and sort it by colour.
