DMX512 LED Controller Kit with Arduino Uno + LED
Build a Professional DMX512 Stage Light Controller with Arduino Uno
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-5 days.
Take command of professional lighting rigs with your own Arduino-powered DMX512 controller. This kit lets you send precise lighting cues to a WS2812B LED strip—the same protocol used in concerts, theaters, and live events. You'll build the hardware, write the code, and watch your light show respond in real time, exactly like a real stage console.
What You'll Build
A fully functional DMX512 transmitter that sends intensity, color, and effect commands over RS485. The included 30-LED strip acts as your stage fixture, responding to your Arduino code. After mastering the basics, you can connect to actual DMX-compatible spotlights and wash lights to run your own mini light show.
What You'll Learn
- Sending DMX512 frames using the MAX485 RS485 transceiver
- Programming Arduino for real-time lighting control sequences
- Addressing and controlling WS2812B LEDs via DMX protocol
- Assembling and soldering a reliable communication circuit on prototype board
Kit Contents
| Component | Quantity |
|---|---|
| Arduino Uno R3 | 1 |
| MAX485 RS485 | 1 |
| WS2812B 30-LED Strip | 1 |
| 470Ω Resistors | 5 |
| 120Ω Resistors | 3 |
| 1000µF 6.3V Capacitors | 2 |
| PCB Prototype Board | 2 |
| 5V 3A Power Supply | 1 |
| Soldering Iron | 1 |
| Solder Wire | 1 |
Why Buy This Kit Instead of Sourcing Parts Separately
| Factor | Sourcing Separately | Compoden Kit |
|---|---|---|
| Compatibility checks | You verify every part | Pre-tested as a system |
| Build support | Forums and scattered tutorials | AI companion trained on this exact project |
| Time to first working build | Days of debugging | Hours, with step-by-step guidance |
| Shipping coordination | Multiple sellers, multiple delays | One shipment from Bengaluru in 3-5 days |
Who This Kit Is For
Perfect for CBSE Class 11-12 students building communication protocol projects, B.Tech ECE/EEE learners diving into industrial lighting standards, and Smart India Hackathon teams prototyping stage automation. ATL Tinkering Labs and hobbyists wanting to understand how real concert lighting works will also love this hands-on experience.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
Scan the QR code to access the AI companion, pre-loaded with every step. If you need a human, message us on WhatsApp — we'll get back within a few hours.
Can I control a real DMX light with this kit?
Yes, the MAX485 output conforms to DMX512 standard; you can connect to any DMX-compliant fixture with the proper XLR cable (not included).
Do I need prior soldering experience?
The kit includes a soldering iron and solder wire; basic soldering skills are helpful but we include clear visual guides to get you started on the prototype board.
Will the code work with LED strips longer than 30 LEDs?
The included WS2812B strip has 30 LEDs, but the Arduino library supports hundreds. You'll need a higher current power supply for larger setups; the logic remains the same.
MAX485 RS485 transceiver sends DMX512 protocol to control professional stage LED fixture from Arduino.
What's in this kit
- Arduino Uno R3
- MAX485 RS485
- WS2812B 30-LED Strip
- 470Ω Resistors x5
- 120Ω Resistors x3
- 1000µF 6.3V Caps x2
- PCB Prototype Board x2
- 5V 3A PSU
- Soldering Iron
- Solder Wire
Choose your assembly option:
- Soldering Kit — 25W soldering iron, 60/40 solder wire, flux, and small perfboard for permanent assembly.
- Breadboard Combo — 800-point full-size breadboard with 65-piece jumper wire pack for solderless prototyping.
Shipping Information
- Prepaid Orders: ₹75 for orders up to ₹999, FREE shipping above ₹999
- COD Orders: ₹125 shipping + ₹50 COD fee = ₹175 total
- Delivery Timeline: Dispatch in 1-2 days, delivery in 2-7 days depending on location
Returns & Warranty
- 7-Day Return: Manufacturing defects only (approval required)
- Warranty: 7 days from delivery
- Non-Returnable: Batteries, consumables, cut wires, clearance items
