Galvanic Cell EMF Comparator Kit with Arduino Uno

SKU: CDN-KIT-1539-CL Brand: Compoden Category: Electronics > School & STEM Projects > Project Kits
Rs. 1,090.00
Inclusive of all taxes
Free Shipping on prepaid orders above ₹1,999
Ships in 3-7 days
7-Day Warranty on manufacturing defects
GST invoice 18% GST included · HSN 90230090
Pay with UPI Cards Netbanking Cash on Delivery
Need 10+ units? Contact us for bulk pricing
100% Genuine Products
Expert Technical Support
Quality Tested
Soldr.ai Ask about this product

Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts

Galvanic Cell EMF Comparator Kit with Arduino Uno — a beginner-level kit.

Measure Galvanic Cell EMF with Arduino Uno – Build a Precision Electrochemical Series Plotter

Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.

Difficulty: Beginner Build Time: 2-3 hrs Skill: Electrochemistry & Analog Measurement

Ever wondered why a zinc-copper cell produces a different voltage than zinc-iron? With this kit, you'll build a high-precision EMF measurement system using an ADS1115 16-bit ADC and Arduino Uno, then automatically read and log voltages from multiple metal pair galvanic cells. The 16x2 LCD displays real-time voltage, and you can export data to plot the electrochemical series—turning a theoretical chemistry concept into a hands-on experiment that meets CBSE and STEM curriculum goals.

What You'll Build

A portable instrument that measures microvolt-level differences between two metal electrodes in salt solutions. After assembling the circuit on a breadboard and connecting the ADS1115 via I2C, you'll clip the electrode pairs, observe the EMF on the LCD, and record values to rank metals by their reduction potential. The result is a working scientific instrument and a clear visual plot of the electrochemical series.

What You'll Learn

  • Interface a precision ADC (ADS1115) with Arduino over I2C to read analog voltages without noise
  • Understand the electrochemical basis of galvanic cells and standard electrode potentials
  • Program an LCD display for real-time voltage readout, making data logging intuitive
  • Calibrate and validate analog measurements to compare theoretical vs. experimental EMF values

Kit Contents

Component Quantity
Arduino Uno R3 x1
ADS1115 ADC x1
16x2 LCD x1
I2C Backpack x1
4.7kΩ Resistors x5
100nF Caps x5
400-pt Breadboard x1
M-M Wires x20
Metal Electrode Set x4
9V Battery Snap x1

Who This Kit Is For

Designed for CBSE students exploring electrochemistry practicals, innovators in ATL Tinkering Labs, and B.Tech first-year ECE/EEE students who need a reliable analog measurement project. Perfect for science fair demonstrations and anyone curious about how battery voltages are determined experimentally.

Built and Backed by Compoden

Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.

What if I get stuck during the build?

Scan the included QR code to launch the AI build companion which walks you through every connection and code step. If you still have questions, WhatsApp our support team for personal guidance.

Can I use different metal pairs not included in the kit?

Absolutely. The ADC and electrode clips are universal. Any two conductive metals (like a zinc nail and a copper coin) can be tested, as long as they are immersed in an electrolyte.

Does this kit require a computer to program the Arduino?

Yes, you need a laptop or desktop to upload the provided code via USB. The AI companion includes setup instructions for Windows, Mac, and Linux.

How accurate are the EMF measurements compared to a digital multimeter?

The ADS1115 offers 16-bit resolution with programmable gain, achieving accuracy within a few millivolts—enough to clearly rank metal pairs. It surpasses typical multimeters for small voltage differences in school lab conditions.

ADS1115 precision ADC measures EMF of different metal pair galvanic cells. Plots electrochemical series.
