Humidity Display Kit with Arduino Uno + DHT22

SKU: CDN-KIT-0106-CL Brand: Compoden Category: Electronics > Weather & Environment > Project Kits
Rs. 892.00
Inclusive of all taxes
Free Shipping on prepaid orders above ₹1,999
Ships in 3-7 days
7-Day Warranty on manufacturing defects
GST invoice 18% GST included · HSN 90230090
Pay with UPI Cards Netbanking Cash on Delivery
Need 10+ units? Contact us for bulk pricing
100% Genuine Products
Expert Technical Support
Quality Tested
Soldr.ai Ask about this product

Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts

Humidity Display Kit with Arduino Uno + DHT22 — a beginner-level build.

Build a Humidity Comfort Display with Arduino Uno, DHT22 and a 16x2 LCD

Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.

Difficulty: Beginner Build Time: 2-3 hrs Skill: Sensor readings and custom LCD graphics

Is the room too dry, comfortable or too humid? The DHT22 reads temperature and humidity, and the Arduino Uno shows them on a 16x2 LCD with a bar graph that moves through dry, comfortable and humid zones.

What You'll Build

You wire the DHT22 module to a digital pin and the I2C LCD to the Uno's SDA and SCL pins on the breadboard. The sketch reads the sensor every two seconds, prints temperature and humidity on the top line, and draws a custom-character bar on the bottom line that fills as humidity rises.

What You'll Learn

  • Reading temperature and humidity from a DHT22
  • Using an I2C character LCD with only two data wires
  • Designing custom LCD characters for a bar graph
  • Mapping a reading onto comfort bands

Kit Contents

Component Quantity
Arduino Uno R3 CH340G 1
DHT22 (AM2302) Temperature and Humidity Sensor Module 1
16x2 I2C Character LCD Display Module (1602 + PCF8574, pre-soldered) 1
400-point solderless breadboard 1
Dupont Jumper Wire Kit (M-M, M-F, F-F, 20cm, 22AWG) 1

Who This Kit Is For

Beginners who want a first useful display project for a bedroom, study or storage cupboard.

Built and Backed by Compoden

Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.

Which sensor does this kit use?

The DHT22 (AM2302), which reads temperature and humidity with good accuracy over a wide range.

My LCD is blank. What should I check?

Turn the contrast trimmer on the back of the LCD and check its I2C address, often 0x27 or 0x3F.

How often can the DHT22 be read?

About once every two seconds. Reading faster returns stale values or errors.

Do you deliver across India?

Yes. We ship Humidity Display Kit with Arduino Uno + DHT22 across India including Delhi, Mumbai, Bangalore, Hyderabad, Chennai, and Pune. Orders ship in 3-7 days.

What payment options are available for Humidity Display Kit with Arduino Uno + DHT22?

We accept UPI, all major debit and credit cards, and Cash on Delivery (COD) available.

Built and shipped from Compoden, with UPI and cards, plus COD available.

Shipping Information

  • Prepaid Orders: ₹45 for orders up to ₹1,999, FREE shipping above ₹1,999
  • COD Orders: ₹45 shipping for orders up to ₹1,999, FREE shipping above ₹1,999. COD available.
  • Delivery Timeline: Dispatch in 3-7 days, delivery in 2-7 days depending on location

Returns & Warranty

  • 7-Day Return: Manufacturing defects only (approval required)
  • Warranty: 7 days from delivery
  • Non-Returnable: Batteries, consumables, cut wires, clearance items
