PIR Outdoor Floodlight Timer Kit with Arduino Uno + LDR
Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts
PIR Outdoor Floodlight Timer Kit with Arduino Uno + LDR — a intermediate-level build.
Build a Dusk-Aware Motion Light Timer with Arduino Uno, PIR, LDR and a Relay Module
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.
A light that turns on only when it is dark and someone is moving, then switches off after a delay you choose. The HC-SR501 PIR sensor notices movement, the LDR module tells day from night, and the Arduino Uno controls a relay module that switches a low-voltage lamp or LED strip.
What You'll Build
You wire the PIR sensor, the LDR module and the relay module's control side to the Uno on the breadboard. The sketch checks the light level, starts a timer when the PIR fires after dark, and keeps the relay on while movement continues. For testing, switch a 12 V LED strip or lamp with its own supply through the relay contacts. Anything on mains must be wired by a qualified person.
What You'll Learn
- Reading a PIR motion sensor and an LDR module together
- Writing a non-blocking timer with millis()
- Controlling a relay module from an Arduino pin
- Testing whether a relay module switches on HIGH or LOW
Kit Contents
| Component | Quantity |
|---|---|
| Arduino Uno R3 CH340G | 1 |
| HC-SR501 PIR Motion Sensor Module | 1 |
| LDR Sensor Module with LM393 | 1 |
| 5V Single Channel Relay Module | 1 |
| 400-point solderless breadboard | 1 |
| Dupont Jumper Wire Kit (M-M, M-F, F-F, 20cm, 22AWG) | 1 |
Who This Kit Is For
Makers who want a practical automation project for a porch, a stairway or a garden path, built and tested at low voltage.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We’ve spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
Can I connect a mains floodlight?
Mains wiring must be done by a qualified person in a proper enclosure. Build and test with a low-voltage lamp or LED strip.
How do I stop it switching on in daylight?
Adjust the LDR module's threshold trimmer and set the light level in the code.
Why does the light stay on longer than my timer?
The PIR sensor has its own hold time. Set its time trimmer to the minimum and let the Arduino control the delay.
Arduino Uno motion light timer: a PIR and an LDR switch a relay module after dark, tested with a low-voltage lamp.
