Thrust Stand Force Gauge Kit with Arduino Uno & OLED — Measure Motor Thrust and Impulse with Precision

Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-5 days.

Testing small solid-fuel rocket motors requires a reliable way to measure thrust curves and total impulse. This kit turns an Arduino Uno into a precision force gauge, using a 5 kg load cell and HX711 amplifier to capture live thrust data, an OLED to display real-time readings, and a microSD module with RTC to timestamp and store every data point. Whether you’re validating a model rocket engine for a CBSE Physics project or iterating on a prototype for the Smart India Hackathon, you’ll have a complete sensor-to-logger system ready in one session.

What You'll Build

You’ll assemble a self-contained thrust stand that secures a small motor, samples force readings at high speed, and shows live thrust and total impulse on the 0.96-inch OLED. All session data is saved to microSD with exact timestamps from the DS3231 real-time clock, so you can plot thrust curves later in any spreadsheet. The setup is rugged enough for bench testing and portable for demo events.

What You'll Learn

• Calibrating a strain-gauge load cell with the HX711 24-bit ADC
• Interfacing an I2C OLED to display live numerical values and simple graphs
• Logging sensor data to microSD with accurate timestamps using an RTC
• Computing impulse from real-time force integration and understanding rocket motor performance curves

Kit Contents

Why Buy This Kit Instead of Sourcing Parts Separately

Who This Kit Is For

CBSE Class 11–12 students working on physics or rocketry projects who need a calibrated thrust measurement system. B.Tech ECE/EEE undergrads prototyping sensor modules for Smart India Hackathon or IIT/NIT rocketry team competitions. ATL Tinkering Lab instructors and hobbyists wanting to add real-time data logging to their model rocket experiments.

Built and Backed by Compoden

Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We’ve spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
