Self-Calibrating Encoder Robot Kit: Uno, LM393, 2WD Chassis
Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts
Self-Calibrating Encoder Robot Kit: Uno, LM393, 2WD Chassis — an intermediate-level kit.
Self-Calibrating Encoder Robot Kit: Uno, LM393, 2WD Chassis
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.
Kit at a glance
What you build: A self-calibrating encoder robot: LM393 speed sensors count each wheel's turns, and on start-up an Arduino Uno compares the two wheels and adjusts their motor power so the robot drives straight, with the counts on an OLED.
What's in the box
- Arduino Uno R3
- LM393 Speed Sensor × 2
- L298N Driver
- TT Gear Motor × 2
- 2WD Chassis
- 18650 Cell × 2
- 18650 2-Cell Holder
- 10kΩ Resistors × 5
- 100nF Caps × 5
- 0.96in OLED
- M-M Wires × 25
Power: two 18650 cells included. A charger is not included.
Skill level: Intermediate (4-5 hours).
Frequently asked questions
Why does a robot drift?
Two cheap motors never spin at exactly the same speed.
How straight will it go?
Much straighter than without calibration; test it on your floor.
Ever built a differential-drive robot that stubbornly curves left despite identical motor specs? Tiny differences in wheel diameter, tread wear, or surface grip cause drift that ruins autonomous runs. This kit eliminates that frustration. On startup, its LM393 encoders perform an auto-calibration routine—measuring each wheel’s true circumference during a short spin-up—so the robot can hold a straight line within 1% error. You’ll assemble a fully intelligent two-wheel platform that knows exactly how far it has traveled, making it ideal for competition robotics, maze solving, or any project where precision matters.
What You'll Build
A complete differential-drive robot that uses optical slot-type encoders to read wheel rotations in real time. The onboard Arduino runs a calibration sequence on every boot, correcting for surface-induced traction changes. Once calibrated, the robot drives straight, turns accurately by degree, and displays telemetry on the OLED screen. It becomes a reliable testbed for advanced navigation, line-following, or even small-scale delivery experiments.
What You'll Learn
- Reading pulse trains from LM393 speed sensors and converting them to distance traveled
- Implementing closed-loop feedback control to maintain heading with encoder-based correction
- Designing an automatic wheel-diameter calibration algorithm that compensates for manufacturing tolerances
- Interfacing I2C OLED displays to show real-time speed, distance, and calibration status
Kit Contents
| Component | Quantity |
|---|---|
| Arduino Uno R3 | 1 |
| LM393 Speed Sensor | 2 |
| L298N Driver | 1 |
| TT Gear Motor | 2 |
| 2WD Chassis | 1 |
| 18650 Cell | 2 |
| 18650 2-Cell Holder | 1 |
| 10kΩ Resistors | 5 |
| 100nF Caps | 5 |
| 0.96in OLED | 1 |
| M-M Wires | 25 |
Who This Kit Is For
CBSE students taking physics or computer science will find a hands-on exploration of feedback systems. B.Tech ECE and EEE undergraduates can validate control theory on real hardware. The kit’s precision also suits Smart India Hackathon teams, ATL Tinkering Lab mentors, and participants from IIT, NIT, VIT, or BITS Pilani who need a repeatable platform for autonomous navigation challenges.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
Open the AI companion or message us on WhatsApp. You’ll get debugging help specific to this kit’s wiring and code.
Do I need prior Arduino experience?
Basic knowledge of uploading sketches is helpful, but the AI companion explains every line and connection. The kit is designed for intermediate makers ready to move beyond simple motor control.
Can I use the chassis for line-following or maze-solving?
Yes. The encoder feedback lets you program precise turns and straights. The self-calibration keeps your robot on track even after swapping wheels or running on new surfaces.
How does auto-calibration work on different floor types?
The robot runs a short calibration sequence, counting encoder pulses per wheel revolution on your actual surface. It then adjusts its motion model instantly, compensating for tile, carpet, or slight tread wear.
What's in this kit
- Arduino Uno R3
- LM393 Speed Sensor x2
- L298N Driver
- TT Gear Motor x2
- 2WD Chassis
- 18650 Cell x2
- 18650 Holder
- 10kΩ Resistors x5
- 100nF Caps x5
- 0.96in OLED
- M-M Wires x25
