TT Gear Motor - High Torque DC Motor for Arduino & Robotics
TT Gear Motor
The TT Gear Motor is a compact DC motor with an integrated gearbox, commonly used in small robotics and DIY electronics. It operates on 3-6V DC and provides high torque at low RPM, making it suitable for driving wheels, conveyor belts, or simple actuators. Its dual-shaft design allows easy mounting of wheels and encoders.
Key Specifications
| Specification | Value |
|---|---|
| Gear Ratio | 1:48 |
| Operating Voltage | 3V - 6V DC |
| No-load Speed (6V) | ~200 RPM |
| Stall Torque (6V) | 0.8 kgĀ·cm (approx) |
| Shaft Type | Dual (both sides) |
| Dimensions | 70 x 37 x 22 mm |
What You Can Build With This
- Arduino or ESP32 two-wheel robot car chassis
- Obstacle-avoiding robot with ultrasonic sensors
- Line-following robot using IR sensors
- Small conveyor belt or automatic plant watering system
Compatibility
The TT Gear Motor works with any microcontroller board capable of PWM output, such as Arduino Uno, Nano, ESP32, Raspberry Pi Pico, or STM32. For motor driving, use a dual H-bridge module like L298N or L293D. The 3ā6V range makes it suitable for battery-powered builds using Li-ion or AA cells.
Wiring Notes
Connect the motor terminals to the output of a motor driver. Do not power directly from a microcontroller GPIO pin; use a separate power source with sufficient current (at least 500mA per motor). For speed control, apply PWM to the driver's enable pin.
Why Buy from Compoden
Every component is sourced from verified suppliers and tested for compatibility before listing. We've spent 10 years building projects for makers, schools, and institutions across India. Ships from Bengaluru in 3-5 days. If defective on arrival, replace within 7 days.
Is this compatible with Arduino Uno?
Yes, with a motor driver like L298N or L293D, the TT Gear Motor can be controlled by Arduino Uno using PWM signals.
What size wheels fit this motor?
The shaft diameter is 5.5mm with a flat side. Standard TT motor wheels with a matching hub press-fit directly.
Can I use this for a drone?
No, this gear motor is too heavy and slow for drone propulsion. It's intended for ground robots or low-speed applications.
