Raspberry Pi Zero 2 W
The Raspberry Pi Zero 2 W packs a quad-core 1GHz processor, 512MB RAM, and wireless connectivity into the Zero form factor. It's a compact single‑board computer for embedded projects, retro gaming, and IoT devices that need more power than the original Zero.
Key Specifications
| Specification | Value |
|---|---|
| Processor | Broadcom BCM2710A1, quad-core Cortex-A53 @ 1GHz |
| RAM | 512MB LPDDR2 SDRAM |
| Wireless Connectivity | 2.4GHz 802.11 b/g/n WiFi, Bluetooth 4.2 (BLE) |
| GPIO Header | 40-pin HAT‑compatible (unpopulated) |
| Video Output | Mini HDMI (1080p @ 30fps) |
| Power Supply | 5V via microUSB (~150 mA typical) |
What You Can Build With This
- Portable retro gaming console with RetroPie or Lakka
- Smart home sensor hub with WiFi and BLE (temperature, motion, air quality)
- IoT weather station that logs data and sends alerts via the cloud
- Compact network‑attached storage (NAS) or ad‑blocker with Pi‑hole
Compatibility
The Pi Zero 2 W runs Raspberry Pi OS (Raspbian), RetroPie, DietPi, and most ARM Linux distributions. It works with standard 40‑pin HATs, Raspberry Pi Camera Modules, and USB OTG accessories. Input power is 5V through the microUSB port or GPIO pins 2/4.
Wiring Notes
Use a 5V power supply with at least 1A current capacity. The single microUSB port handles both power and USB OTG data; to use a USB peripheral while powering the board, employ a USB OTG Y‑cable. All GPIO pins operate at 3.3V logic and are not 5V‑tolerant.
Why Buy from Compoden
Every component is sourced from verified suppliers and tested for compatibility before listing. We've spent 10 years building projects for makers, schools, and institutions across India. Ships from Bengaluru in 3-5 days. If defective on arrival, replace within 7 days.
Is this compatible with RetroPie?
Yes, the Pi Zero 2 W runs RetroPie smoothly for classic consoles up to PlayStation 1. You’ll need a microSD card loaded with the image and a USB controller.
Can I use it as a desktop computer?
It can run lightweight desktops such as Raspberry Pi OS Lite or DietPi, but 512MB RAM limits multitasking. It’s suitable for single‑task programming, browsing, or file serving.
Does it come with a soldered GPIO header?
No, the 40‑pin header is unpopulated by default. You can solder a male header yourself or use a hammer‑fit/solderless header kit.
