HS-F08B Vibration Sensor Module with Red LED Indicator
HS-F08B LED Signal Indicator Sensor Module - Red
The HS-F08B is a vibration sensor module designed to detect physical vibration or tilt and output a digital signal. It features an onboard red LED that illuminates when vibration is detected, providing instant visual feedback. Suitable for alarm systems, motion triggers, and interactive projects.
Key Specifications
| Specification | Value |
|---|---|
| Operating Voltage | 3.3Vā5V DC |
| Output Type | Digital (high/low) |
| Sensor Type | Vibration switch (spring type) |
| LED Indicator | Red LED |
| Dimensions | Approx. 15 x 10 mm |
| Mounting | 3-pin header (VCC, GND, OUT) |
What You Can Build With This
- Vibration alarm system for doors or windows
- Tap-sensitive light controller
- Shake-to-activate gadget
- Machine vibration monitoring with Arduino
Compatibility
This module operates at 3.3Vā5V, making it compatible with Arduino, Raspberry Pi, ESP8266, ESP32, and most microcontrollers. Its digital output connects directly to any digital input pin without level shifting.
Wiring Notes
Connect VCC to 5V (or 3.3V), GND to ground, and OUT to a digital pin. The onboard comparator provides a clean high/low signal; no pull-up resistors or extra components are needed.
Why Buy from Compoden
Every component is sourced from verified suppliers and tested for compatibility before listing. We've spent 10 years building projects for makers, schools, and institutions across India. Ships from Bengaluru in 3-5 days. If defective on arrival, replace within 7 days.
Is this compatible with Arduino Uno?
Yes, the HS-F08B works with Arduino Uno and any board with 3.3Vā5V digital inputs. Simply connect VCC to 5V, GND to GND, and OUT to a digital pin.
Can I adjust the sensitivity?
This module uses a mechanical vibration switch; sensitivity is fixed. For adjustable sensitivity, consider a piezoelectric vibration sensor with analog output.
Does the LED stay on continuously when vibrating?
No, the LED only lights when vibration is detected and turns off when vibration stops. The output signal is momentary and matches the vibration event.
