Auto Light Energy Saver Kit with Arduino Uno + Relay
Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts
Occupancy Energy Saver Kit: Arduino Uno, PIR, Relay, Timer — an intermediate-level kit.
Occupancy Energy Saver Kit: Arduino Uno, PIR, Relay, Timer
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.
Kit at a glance
What you build: An occupancy energy saver: a PIR tells an Arduino Uno when someone is in the room and a relay switches the light or fan on, then off again after 5 minutes with no movement, so nothing runs in an empty room.
What's in the box
- Arduino Uno R3
- HC-SR501 PIR
- 5V Relay Module
- 1N4007 Diode × 5
- 10kΩ Resistors × 5
- 400-pt Breadboard
- M-M Wires × 20
- 12V Adapter
Power: 12V adapter included.
Skill level: Beginner (2-3 hours, no soldering).
Frequently asked questions
Can it switch mains devices?
The relay can, but mains wiring needs a qualified person.
Why 5 minutes?
Long enough that a person sitting still doesn't get left in the dark; change it in code.
Imagine walking into a hostel room and having the light switch on automatically — then never worrying about forgetting to turn it off. This kit lets you build a PIR sensor–driven Arduino relay controller that eliminates wasteful power consumption. Perfect for Indian classrooms, labs, and energy-conscious homes where fans or lights often run unattended for hours.
What You'll Build
You'll assemble a fully functional occupancy-based light or fan controller. The HC-SR501 PIR sensor constantly watches for motion; the Arduino Uno processes the signal and commands a 5V relay module to switch a high-voltage appliance. After exactly 5 minutes of no movement, the relay de-energizes, ensuring zero standby drain. The circuit includes flyback diodes and runs on a breadboard for easy tweaking and debugging.
What You'll Learn
- Interface a PIR sensor with Arduino and calibrate its sensitivity and time delay
- Program a relay control logic with auto-off timer using non-blocking millis() calls
- Understand flyback diode protection for relay coils and safe 5V-to-mains isolation
- Test and debug on a breadboard, then adapt the concept to real-world energy-saving projects
Kit Contents
| Component | Quantity |
|---|---|
| Arduino Uno R3 | 1 |
| HC-SR501 PIR | 1 |
| 5V Relay Module | 1 |
| 1N4007 Diode | 5 |
| 10kΩ Resistors | 5 |
| 400-pt Breadboard | 1 |
| M-M Wires | 20 |
| 12V Adapter | 1 |
Who This Kit Is For
Designed for CBSE students tackling physics or computer science projects, first-year B.Tech ECE/EEE miniprojects, and ATL Tinkering Lab participants. It’s also a strong fit for Smart India Hackathon teams prototyping energy automation and hostel wardens fighting electricity wastage. If you’ve worked with Arduino before and want a practical, measurable automation build — not just theory — you’re ready.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
Scan the QR code to open the AI companion, trained on this kit's wiring and code. It walks you through each connection and logic. If you prefer, message us on WhatsApp — we reply.
Can I use this to control a ceiling fan instead of a light?
Yes, the relay module can handle most table fans or lights up to 10A/250VAC. For ceiling fans, ensure the relay rating matches and connect only to the switch line. The auto-off logic remains the same.
Does it work with a 12V battery instead of the included adapter?
The Arduino Uno accepts 7–12V DC input, so you can power the whole circuit from a 12V battery or solar panel — great for off-grid energy-saving models.
Is this kit safe for a school project demonstration?
Absolutely. The relay module isolates the low-voltage Arduino side from the mains. We include 1N4007 diodes for extra flyback protection. Just follow the build guide and never touch live wires.
Energy Saving — PIR detects occupancy and switches fan relay on. Auto-off after 5 min of no motion.
What's in this kit
- Arduino Uno R3
- HC-SR501 PIR
- 5V Relay Module
- 1N4007 Diode x5
- 10kΩ Resistors x5
- 400-pt Breadboard
- M-M Wires x20
- 12V Adapter
