Seedling Heat Mat Controller Kit: Arduino Uno, DS18B20, PID
Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts
Seedling Heat Mat Controller Kit: Arduino Uno, DS18B20, PID — an intermediate-level kit.
Seedling Heat Mat Controller Kit: Arduino Uno, DS18B20, PID
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.
Kit at a glance
What you build: A seedling heat mat controller: a waterproof DS18B20 under the seed tray tells an Arduino Uno the soil temperature, and it switches a heat mat through a relay with PID control to hold your target. A DHT22 logs the air humidity to microSD for a germination study.
What's in the box
- Arduino Uno R3
- DS18B20 Waterproof
- DHT22
- 5V Relay Module
- DS3231 RTC
- MicroSD Module
- 0.96in OLED
- 4.7kΩ Resistors × 5
- 10kΩ Resistors × 5
- 100nF Caps × 5
- 400-pt Breadboard
- M-M Wires × 25
- 9V Battery Snap
Power: 9V battery, not included; a USB or DC adapter suits it better. The heat mat is not included.
Skill level: Intermediate (4-5 hours).
Frequently asked questions
Which heat mat?
Any seedling mat; mains mats need safe, qualified wiring.
Why PID?
It holds the temperature steadier than simple on-off.
This kit transforms an Arduino Uno into a precision incubator monitor, driving a heat mat via a relay module while a PID algorithm locks the temperature at the exact set point your germination study requires. The waterproof DS18B20 probe reads soil-level heat, the DHT22 captures ambient humidity, and every data point gets a timestamp from the DS3231 RTC before landing on a microSD card. Whether you’re mapping Brassica germination curves for a CBSE biology project or prototyping a smart nursery for a Smart India Hackathon, you get a fully instrumented test bed in one box.
What You'll Build
A self-regulating seedling station that holds a tray at a programmable target temperature using a PID loop. The 0.96-inch OLED cycles through real-time temperature, humidity, set point, and relay status. A microSD module logs every reading with precise timestamps, so you can correlate humidity swings with germination rates over days or weeks. Once calibrated, the system needs no manual tweaking — just plug in any standard 5V or 12V heat mat and let the Arduino run the show.
What You'll Learn
- Implement a software PID controller on Arduino Uno and tune Kp, Ki, Kd for thermal mass
- Interface one-wire DS18B20 and DHT22 sensors, reading accurate temperature and humidity values
- Use a relay module to safely switch a heat mat or other AC/DC load from a microcontroller
- Log sensor data with real-time clock stamps to a microSD card in CSV format for Excel or Python analysis
Kit Contents
| Component | Quantity |
|---|---|
| Arduino Uno R3 | 1 |
| DS18B20 Waterproof | 1 |
| DHT22 | 1 |
| 5V Relay Module | 1 |
| DS3231 RTC | 1 |
| MicroSD Module | 1 |
| 0.96in OLED | 1 |
| 4.7kΩ Resistors | 5 |
| 10kΩ Resistors | 5 |
| 100nF Caps | 5 |
| 400-pt Breadboard | 1 |
| M-M Wires | 25 |
| 9V Battery Snap | 1 |
Who This Kit Is For
CBSE students tackling investigatory projects on seed physiology, B.Tech ECE/EEE undergraduates prototyping IoT agriculture modules, and ATL Tinkering Lab mentors who need a reproducible environmental lab. It also fits teams preparing for Smart India Hackathon tracks in agri-tech, as well as hobbyists at IIT, NIT, VIT, or BITS who want to fast-track a data-driven germination study.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
Scan the QR code on the box to chat with the AI build companion, which knows the exact wiring and code for this kit. For trickier questions, our WhatsApp support is active.
Which heat mat works best with this controller?
Any commercially available 5V or 12V seedling heat mat rated under 10A can be switched by the included relay module. The PID algorithm lets you hold the soil temperature within ±0.5°C of the set point.
Can I plot the logged humidity and temperature graphs on a computer?
Yes. The microSD module saves CSV files with timestamps. Simply transfer the card to your laptop and open the data in Excel, Google Sheets, or Python to analyze germination trends over time.
