BLE Proximity Badge Variant 12 Kit with ESP32 + LED
Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts
BLE Proximity Badge Variant 12 Kit with ESP32 + LED — a beginner-level kit.
BLE Proximity Badge Kit with ESP32 – Build a Wireless Attendance Logger in 2 Hours
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.
Kit at a glance
What you build: A two-board Bluetooth tether: one ESP32 is a tag in your bag, and the other watches its signal and lights an LED when the tag moves out of range. You learn how Bluetooth Low Energy beacons and signal strength work, then use it so you never leave the bag behind.
What's in the box
- ESP32 Dev Board × 2
- 5mm LED × 2
- 220Ω Resistors × 5
- 400-pt Breadboard × 2
- M-M Wires × 15
- Micro USB Cable × 2
Power: USB (two cables included). For a portable tag, add a USB power bank (not included).
Skill level: Beginner (2-3 hours, no soldering).
Frequently asked questions
How far is "out of range"?
You set the signal-strength level in code. Walls and bodies change it, so test it in your own space.
Can my phone see the tag?
Yes. A BLE scanner app shows it.
Do I need to solder?
No. Both boards go on the included breadboards.
This kit turns two ESP32 boards into a real-world BLE proximity badge system. One board becomes a compact beacon you can carry in a pocket or wear on a lanyard, advertising a customizable UUID. The second board acts as a base station that lights up an LED the moment it detects the beacon within range. It’s a brilliant way to demonstrate contact tracing, automated attendance, or child proximity alerts while learning core IoT concepts.
What You'll Build
You’ll wire up two independent circuits on breadboards: a battery-powered beacon (simulated with USB power) that constantly broadcasts its presence, and a receiver that scans for that exact signal. When the beacon comes within a few meters, the receiver’s LED blinks, proving the connection
ESP32 advertises a BLE beacon with custom UUID. Second device logs proximity when in range.
What's in this kit
- ESP32 Dev Board x2
- 5mm LED x2
- 220Ω Resistors x5
- 400-pt Breadboard x2
- M-M Wires x15
- Micro USB Cable x2
