Blind Stick Obstacle Detector Kit

SKU: CDN-KIT-2852-SLD Brand: Compoden Category: Electronics > Robotics & Motion > Project Kits
Rs. 4,430.00
Inclusive of all taxes
Free Shipping on prepaid orders above ₹1,999
Ships in 3-7 days
7-Day Warranty on manufacturing defects
GST invoice 18% GST included · HSN 90230090
Pay with UPI Cards Netbanking Cash on Delivery
Need 10+ units? Contact us for bulk pricing
100% Genuine Products
Expert Technical Support
Quality Tested
Soldr.ai Ask about this product

Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts

Blind Stick Obstacle Detector Kit — an advanced-level kit.

GPS-Guided Blind Stick with Virtual Boundary and Obstacle Detection — Advanced Arduino Project Kit

Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.

Difficulty: Advanced Build Time: 8-10 hrs Skill: Sensor Fusion & GPS Navigation

Navigating unfamiliar or open spaces without sight remains one of the hardest daily challenges. This kit lets you build a walking aid that does more than detect obstacles — it creates a programmable GPS boundary that keeps the user within a safe zone, actively steering around objects while logging every movement to an SD card for later review. It blends geofencing, ultrasonic scanning, and motor feedback into a single integrated system you wire and program from scratch.

What You'll Build

A handheld assistive device that reads real-time GPS coordinates and compares them against a user-defined perimeter. When approaching the virtual fence, dual DC motors nudge the stick to redirect the user inward. Three ultrasonic sensors simultaneously scan ahead and to both sides, detecting obstacles above ground level. The entire session — coordinates, obstacle events, and motor corrections — writes continuously to a microSD card for analysis.

What You'll Learn

  • Parsing NMEA sentences from NEO-6M GPS and translating lat-long into actionable course corrections
  • Implementing a trilateration-based obstacle decision matrix using three HC-SR04 sensors with interrupt-driven timing
  • Driving 12V DC motors through an L298N dual H-bridge with PWM speed control and coordinated differential steering
  • Designing a reliable power stage with SLA battery, buck converter regulation, and multi-point decoupling across prototype boards

Kit Contents

Component Quantity
Arduino Nano 1
HC-SR04 2
Coin vibration motor 1
Active buzzer 1
18650 cell 2
2-cell 18650 holder 1
2S pack charger 1
Jumper wires 1

Who This Kit Is For

This is a natural project choice for B.Tech ECE and EEE students in their final year who need a working assistive technology prototype with documentation potential. Smart India Hackathon participants working on disability or accessibility problem statements will find the GPS geofencing and obstacle logging directly relevant. ATL Tinkering Lab instructors and mentors at IIT, NIT, and VIT can use this kit to teach sensor fusion, power management, and soldering in a single semester-long build.

Built and Backed by Compoden

Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.

What if I get stuck during the build?

Scan the QR code inside the box to start a session with the AI companion trained on this exact circuit and code; if you need a human, our engineers reply over WhatsApp.

How do I define the virtual fence boundary?

You'll pre-load an array of GPS waypoints into the Arduino Mega's sketch. The system calculates distance from current position to each boundary segment and triggers motor correction when you cross a configurable warning radius.

How long does the SLA battery run this setup?

The 12V 5Ah SLA battery powers the Mega, GPS, three ultrasonics, and both motors for approximately 4-5 hours of continuous walking navigation before needing a recharge.

Can I view the logged obstacle and path data on a computer?

Yes. The microSD module writes timestamped GPS coordinates and obstacle trigger events to a CSV file. Remove the card, insert it into any laptop, and open the file in Excel or any text editor for path visualization and analysis.

Accessibility — GPS boundary following with obstacle avoidance. Stays within virtual fence. Logs path to SD.

What's in this kit

Choose your assembly option:

  • Soldering Kit — 25W soldering iron, 60/40 solder wire, flux, and small perfboard for permanent assembly.
  • Breadboard Combo — 800-point full-size breadboard with 65-piece jumper wire pack for solderless prototyping.

Shipping Information

  • Prepaid Orders: ₹45 for orders up to ₹1,999, FREE shipping above ₹1,999
  • COD Orders: ₹45 shipping for orders up to ₹1,999, FREE shipping above ₹1,999. COD available.
  • Delivery Timeline: Dispatch in 3-7 days, delivery in 2-7 days depending on location

Returns & Warranty

  • 7-Day Return: Manufacturing defects only (approval required)
  • Warranty: 7 days from delivery
  • Non-Returnable: Batteries, consumables, cut wires, clearance items
