Earthquake Vibration Logger Kit
Earthquake Vibration Logger Kit: Master Control Systems with Real-Time NEMA17 Stepper Balancing
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-5 days.
This is a capstone control systems build that turns raw vibration data into active stabilization. You’ll assemble a seismology-grade logging platform where MPU6050 accelerometer readings feed a tuned PID loop, driving two NEMA17 steppers to keep a vertical balance plate level — exactly the kind of project that earns top marks in a B.Tech final-year submission or shines at Smart India Hackathon.
What You'll Build
By the end of this build, you’ll have a fully functional seismic vibration logger. The platform actively counters tilt in real time, records accelerometer data, and demonstrates closed-loop control. Use it as a portable earthquake simulator, a teaching aid for control system labs, or a base for advanced stabilization experiments.
What You'll Learn
- Tune a PID controller for real-world stepper motor dynamics
- Fuse MPU6050 accelerometer and gyroscope data for precise tilt sensing
- Drive NEMA17 steppers with A4988 microstepping drivers
- Log and visualize vibration patterns for seismology analysis
Kit Contents
| Component | Quantity |
|---|---|
| Arduino Uno R3 | 1 |
| MPU6050 | 1 |
| A4988 Driver | 2 |
| NEMA 17 Stepper 40Ncm | 2 |
| 80mm Rubber Wheel | 2 |
| LM2596 Buck Converter | 1 |
| 3S LiPo 1300mAh | 1 |
| XT60 Connector | 1 |
| 100nF Caps | 10 |
| 100µF 25V Caps | 4 |
| 4.7kΩ Resistors | 5 |
| 10kΩ Resistors | 5 |
| PCB Prototype Board | 2 |
| Acrylic Plate 200x100mm | 2 |
| M3 Standoffs 30mm | 8 |
| M3 Bolts+Nuts | 20 |
| Soldering Iron | 1 |
| Solder Wire | 1 |
Why Buy This Kit Instead of Sourcing Parts Separately
| Factor | Sourcing Separately | Compoden Kit |
|---|---|---|
| Compatibility checks | You verify every part | Pre-tested as a system |
| Build support | Forums and scattered tutorials | AI companion trained on this exact project |
| Time to first working build | Days of debugging | Hours, with step-by-step guidance |
| Shipping coordination | Multiple sellers, multiple delays | One shipment from Bengaluru in 3-5 days |
Who This Kit Is For
Final-year B.Tech ECE, EEE, or Mechatronics students tackling capstone control systems will find this kit a rigorous yet manageable entry. It’s also a strong pick for Smart India Hackathon hardware tracks, IIT/NIT/VIT project submissions, and advanced ATL Tinkering Labs where mentors want to demonstrate PID theory with live hardware.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
Scan the QR code to chat with the AI companion, which walks you through every step; if you need a human, our support team replies on WhatsApp within hours.
Do I need prior PID controller experience?
Basic familiarity with control loop concepts helps, but the companion explains tuning from scratch — many builders use this kit to learn PID in practice for the first time.
Can I use the built logger for actual seismology experiments?
Yes, the MPU6050 data stream logs real vibrations, and you can export it to MATLAB or Python for analysis. It’s sensitive enough to detect footfall tremors on a table.
Is the soldering difficult for this kit?
The prototype board and connectors need basic through-hole soldering; the included soldering iron and clear instructions make it manageable even if your only prior experience is a lab session.
Seismology — NEMA17 steppers driven by A4988 with MPU6050 PID loop maintain vertical balance. Capstone control systems build.
What's in this kit
- Arduino Uno R3
- MPU6050
- A4988 Driver x2
- NEMA 17 Stepper 40Ncm x2
- 80mm Rubber Wheel x2
- LM2596 Buck Converter
- 3S LiPo 1300mAh
- XT60 Connector
- 100nF Caps x10
- 100µF 25V Caps x4
- 4.7kΩ Resistors x5
- 10kΩ Resistors x5
- PCB Prototype Board x2
- Acrylic Plate 200x100mm x2
- M3 Standoffs 30mm x8
- M3 Bolts+Nuts x20
- Soldering Iron
- Solder Wire
Choose your assembly option:
- Soldering Kit — 25W soldering iron, 60/40 solder wire, flux, and small perfboard for permanent assembly.
- Breadboard Combo — 800-point full-size breadboard with 65-piece jumper wire pack for solderless prototyping.
