Earthquake Vibration Logger Pro Kit — Real Seismology with Arduino Uno and MPU6050

Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-5 days.

Earthquakes fascinate young minds, but building a device that actually senses and records tremors takes that curiosity to the next level. This kit lets you assemble a working vibration logger using a precision load cell to measure force and an MPU6050 accelerometer to capture motion—then you’ll verify Newton’s F = ma by plugging live sensor readings into the equation. It’s a hands-on physics lab, an Arduino project, and a real-world seismology simulation all in one.

What You'll Build

You’ll wire up a complete sensor array on a breadboard, load the Arduino with data-logging code, and mount the load cell so that any shake or tap produces a measurable force. The MPU6050 simultaneously tracks acceleration along three axes, and both values stream to the 16x2 LCD. By comparing force from the load cell against mass × acceleration from the MPU6050, you’ll confirm F = ma with your own data—just like a seismologist analyzing ground motion.

What You'll Learn

• Interface an HX711 load cell with Arduino and calibrate it for force measurements
• Read 3‑axis acceleration from the MPU6050 over I2C and translate raw values into m/s²
• Log and display real‑time data on a 16x2 LCD using an I2C backpack
• Experimentally verify Newton’s second law by plotting force versus mass × acceleration

Kit Contents

Why Buy This Kit Instead of Sourcing Parts Separately

Who This Kit Is For

Students aged 10–15 who love tinkering and physics will find this kit captivating, especially when they see F=ma come alive on screen. It’s ideal for CBSE Class 7–12 science projects, ATL Tinkering Lab sessions, and early engineering experiments at school level. Even first‑year B.Tech ECE/EEE students can use it as a foundational sensor‑integration assignment.

Built and Backed by Compoden

Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
