Earthquake Vibration Logger Pro Kit with ESP32 + MPU6050 — Build a Wearable AI Seismograph
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-5 days.
This kit turns you into a builder of life-saving wearable technology. You'll create a wristband that monitors ground vibrations, distinguishes earthquake tremors from ordinary bumps using a TensorFlow Lite model on the ESP32-S3, fuses GPS coordinates and heart rate data, and triggers a GSM emergency alert when a fall is detected. It’s a complete edge-AI project that mirrors real-world disaster response and biomedical engineering challenges.
What You'll Build
You'll assemble a wrist-worn seismograph that logs MPU6050 acceleration, displays live data and SpO2 on an OLED screen, and classifies falls vs. normal activity. The device locks GPS location at the moment of impact and automatically sends an SMS through the SIM800L module, giving you a functional prototype for rapid emergency response in earthquake‑prone areas.
What You'll Learn
- Apply sensor fusion algorithms to combine MPU6050 motion data, MAX30102 pulse oximeter readings, and NEO-6M GPS coordinates
- Deploy a TensorFlow Lite model on the ESP32-S3 for real‑time fall and vibration classification
- Program the SIM800L GSM module to dispatch emergency SMS with location
- Design power‑aware wearable electronics using a LiPo battery, TP4056 charger, and LM2596 buck converter
Kit Contents
| Component | Quantity |
|---|---|
| ESP32-S3 Dev Board | 1 |
| MPU6050 | 1 |
| MAX30102 | 1 |
| NEO-6M GPS | 1 |
| SIM800L GSM | 1 |
| LM2596 Buck Converter | 1 |
| 3.7V LiPo 1000mAh | 1 |
| TP4056 Module | 1 |
| 0.96in OLED | 1 |
| 1000µF 25V Caps | 2 |
| 100nF Caps | 10 |
| PCB Prototype Board | 2 |
| Velcro Wristband | 1 |
| Soldering Iron | 1 |
| Solder Wire | 1 |
Why Buy This Kit Instead of Sourcing Parts Separately
| Factor | Sourcing Separately | Compoden Kit |
|---|---|---|
| Compatibility checks | You verify every part | Pre-tested as a system |
| Build support | Forums and scattered tutorials | AI companion trained on this exact project |
| Time to first working build | Days of debugging | Hours, with step-by-step guidance |
| Shipping coordination | Multiple sellers, multiple delays | One shipment from Bengaluru in 3-5 days |
Who This Kit Is For
B.Tech ECE/EEE students designing final‑year projects on wearable health monitors or disaster response systems. Participants in Smart India Hackathon building IoT solutions for earthquake‑prone regions. Researchers at IITs, NITs, and BITS Pilani prototyping edge‑AI sensor networks. Anyone over 21 with soldering experience ready to push into embedded machine learning.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
Our AI companion, trained on this exact project, can walk you through every connection and code block. If you need human help, reach out via WhatsApp and our Bengaluru team will respond within 24 hours.
Can I extend this kit to send data to a cloud server?
Absolutely. The ESP32-S3 has Wi‑Fi, so you can add MQTT or HTTP to upload quake logs to AWS IoT or ThingSpeak. The AI companion includes sample code for cloud integration.
Does this kit detect real earthquakes or just vibrations?
The MPU6050 and TensorFlow Lite model are tuned to distinguish seismic P‑waves from everyday movements after proper calibration. A full seismograph requires careful mounting, but the kit’s firmware demonstrates the principle end-to-end.
Is soldering experience required?
Yes. This advanced kit uses bare modules and a PCB prototype board, so you’ll need to solder the components together. We’ve included a soldering iron and solder wire—and the AI guide shows exact pad connections.
Seismology — MPU6050 + MAX30102 SpO2 + GPS fused by ESP32-S3 TFLite model. Classifies fall vs normal activity. GSM SOS.
What's in this kit
Choose your assembly option:
- Soldering Kit — 25W soldering iron, 60/40 solder wire, flux, and small perfboard for permanent assembly.
- Breadboard Combo — 800-point full-size breadboard with 65-piece jumper wire pack for solderless prototyping.
