Hidden Safe IR Beam Kit with Arduino Uno + LED

SKU: CDN-KIT-0461-CL Brand: Compoden Category: Electronics > Security & Surveillance > Project Kits
Rs. 550.00
Inclusive of all taxes
Free Shipping on prepaid orders above ₹1,999
Ships in 3-7 days
7-Day Warranty on manufacturing defects
GST invoice 18% GST included · HSN 90230090
Pay with UPI Cards Netbanking Cash on Delivery
Need 10+ units? Contact us for bulk pricing
100% Genuine Products
Expert Technical Support
Quality Tested
Soldr.ai Ask about this product

Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts

Hidden Safe IR Beam Kit with Arduino Uno + LED — a beginner-level kit.

Build Your Own Hidden Safe IR Beam Alarm with Arduino Uno

Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.

Difficulty: Beginner Build Time: 1-2 hrs Skill: Infrared security system logic

Keep your secrets safe with a working alarm that screams the moment a curious sibling or intruder opens your safe while you’re away. This kit places an invisible infrared beam across the safe opening – when the main door is locked and someone tries to slip inside, the beam breaks and a buzzer shrieks instantly. You’ll mount an IR LED and photodiode on opposite sides, wire them to an LM393 comparator, and program an Arduino Uno to trigger the alarm only when the door is truly closed. It’s a real security gadget you can deploy at home, in a school locker, or as a live demo for your next science exhibition.

What You’ll Build

You’ll assemble a battery-powered hidden safe monitor that fits neatly inside any cupboard, locker, or strongbox. The IR beam stays invisible to the naked eye, so tamperers won’t notice it until the buzzer sounds. By coding a simple logic check, the Arduino ensures the alarm doesn’t go off just because you opened the main door – it only reacts when the door is locked and the beam is broken. The final device teaches you how professional security systems use light beams to guard vaults and how comparators turn analog sensor signals into digital alerts.

What You’ll Learn

  • How infrared LEDs and photodiodes detect interruption in a light path
  • Using an LM393 comparator to convert analog sensor readings to a digital trigger
  • Programming conditional logic in Arduino IDE to check lock status before sounding an alarm
  • Breadboarding a real-world sensor circuit with resistors, jumper wires, and a 9V power supply

Kit Contents

Component Quantity
Arduino Uno R3 1
IR LED 1
IR Photodiode 1
Active Buzzer 1
LM393 Comparator 1
220Ω Resistors 5
10kΩ Resistors 5
400-pt Breadboard 1
M-M Wires 15
9V Battery Snap 1

Who This Kit Is For

Good for tinkerers who want a hands-on security gadget they can use right away. CBSE physics students can demonstrate infrared optics and comparator circuits, while ATL Tinkering Lab participants and Smart India Hackathon junior tracks will find it a fast, self-contained project. B.Tech ECE first-years at VIT, NIT, or BITS often use this exact kit to grasp sensor integration before moving to advanced embedded systems. It's also a weekend build that ends with a working beam-break alarm.

Built and Backed by Compoden

Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.

What if I get stuck during the build?

Scan the QR code on the box and our AI companion will walk you through the exact wiring and code, step by step. If you prefer a human, WhatsApp us — a real mentor replies.

Can this work without an Arduino board?

The kit uses an Arduino Uno R3 to read the comparator output and manage the lock/unlock logic. You could replicate it with a standalone comparator, but the Arduino makes it programmable and easy to adapt later.

Will the IR beam work in daylight or a bright room?

Yes, the LM393 comparator is tuned to detect the specific IR modulation, so ambient light won’t cause false triggers. You can even demonstrate it near a window.

How do I know if the main door is locked?

You’ll connect a simple switch or magnetic reed sensor (not included but easily added) to one of the Arduino’s digital pins, then code the alarm to activate only when that pin reads HIGH (door closed). The instructions show exactly how.

IR beam across safe opening triggers buzzer if tampered while main door is locked.
