Intruder Sequence Classifier Security Kit with ESP32 + HC-SR501 PIR

SKU: CDN-KIT-4008 Brand: Compoden Category: Electronics > AI IoT > Project Kits
Rs. 900.00
Inclusive of all taxes
Free Shipping on prepaid orders above ₹1,999
Ships in 3-7 days
7-Day Warranty on manufacturing defects
GST invoice 18% GST included · HSN 90230090
Pay with UPI Cards Netbanking Cash on Delivery
Need 10+ units? Contact us for bulk pricing
100% Genuine Products
Expert Technical Support
Quality Tested
Soldr.ai Ask about this product

Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts

Intruder Sequence Classifier Kit: ESP32, PIR, Reed Switches — a beginner-level kit.

Intruder Sequence Classifier Kit: ESP32, PIR, Reed Switches

Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.

Difficulty: Beginner Build Time: 3-4 hrs Skill: IoT Event Sequencing & MQTT

Kit at a glance

What you build: An intruder sequence classifier: an ESP32 records the order of events from two door reed switches and a PIR. Opening the front door and then moving inside is routine; motion with no door opened first is suspicious. It classifies each sequence and sends an MQTT alert for the odd ones.

What's in the box

  • ESP32 Dev Board
  • HC-SR501 PIR
  • Reed Switch × 2
  • LED Red × 2
  • Piezo Buzzer
  • MicroUSB Cable
  • M-M Wires × 15

Power: USB. A USB charger is not included.

Skill level: Beginner (3-4 hours).

Frequently asked questions

How does order help?

The same sensors mean different things depending on what happened first.

Is it a certified alarm?

No. It's a learning project.

Turn your ESP32 into a security guard that actually knows the difference between you walking past a sensor and an actual intrusion. This kit gives you the exact sensors and code patterns to build a home security system that watches doors, windows, and motion – then classifies event sequences to eliminate false alarms and fire real MQTT alerts when things look suspicious.

What You'll Build

You’ll assemble a working intrusion detection network with a central ESP32 hub, a PIR motion sensor for room monitoring, and two reed switches on doors or windows. The system continuously reads sensor events, sequences them in time, and applies threshold rules to decide whether a pattern is “normal home movement” or a potential break-in. When an intrusion pattern is detected, the ESP32 publishes an alert via MQTT that can be received by a phone, dashboard, or cloud service.

What You'll Learn

  • Program event-driven logic on the ESP32 to timestamp and correlate PIR and reed switch activations
  • Classify movement patterns using simple window-based rules (routine vs. suspicious sequence)
  • Use MQTT protocol to send real-time security alerts to any broker or client
  • Integrate physical sensors into a lightweight IoT firmware without overwhelming the microcontroller

Kit Contents

Component Quantity
ESP32 Dev Board 1
HC-SR501 PIR 1
Reed Switch 2
LED Red 2
Piezo Buzzer 1
MicroUSB Cable 1
M-M Wires 15

Who This Kit Is For

Designed specifically for CBSE students exploring IoT in their curriculum, ATL Tinkering Lab members preparing for national challenges, and first-year B.Tech ECE/EEE learners who want a working security project for demonstrations or hackathons like Smart India Hackathon. The build complexity is beginner-friendly but the logic teaches pattern classification that maps directly to real-world smart home applications.

Built and Backed by Compoden

Every Compoden kit ships with an AI build companion trained on this exact project – accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.

What if I get stuck during the build?

Open the AI companion via the QR code for step-by-step debugging; if that doesn’t resolve it, message us on WhatsApp for live human guidance.

Can I use this kit with my existing home Wi-Fi?

Absolutely. The ESP32 connects to a 2.4 GHz Wi-Fi network and publishes MQTT alerts to any broker you configure – ideal for integrating into a broader home automation system.

Does the sensor pattern classification work without internet?

The classification logic runs fully on the ESP32 itself, so local detection and buzzer/LED alerts work offline. MQTT alert delivery needs Wi-Fi connectivity to the broker.

What if my PIR sensor triggers too many false alarms?

The AI companion includes tuning tips for the HC-SR501’s sensitivity and time-delay trimmers, plus code examples to set cooldown periods and pattern filters that drastically reduce false positives.

Home Security — PIR and door reed switch event sequences on ESP32 classify intrusion vs routine movement pattern — MQTT security alert.
