Pi Pico 2 Neural Oscillation Kit: Build a Hodgkin-Huxley Neuron Model and See Action Potentials Live
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-5 days.
Step into computational biology with a working Hodgkin-Huxley neuron model running on the Raspberry Pi Pico 2. Twist a potentiometer to inject stimulus current, watch the membrane potential fire an action potential in real time on the 2.4-inch TFT display. This kit transforms abstract differential equations into hardware you can touch and tune.
What You'll Build
You’ll assemble a self-contained neural simulation instrument powered by the Pico 2. The system reads stimulus amplitude from a potentiometer via the ADC, numerically solves the Hodgkin-Huxley ODEs, and plots the action potential waveform on the ILI9341 TFT. The finished device fits in an ABS enclosure, ready for lab demonstrations, hackathons, or your final-year project.
What You'll Learn
- Program the Raspberry Pi Pico 2 in MicroPython to solve differential equations in real time
- Interface ADC, TFT, and tactile buttons on a custom soldered PCB
- Implement the Hodgkin-Huxley model of action potential generation from scratch
- Debug embedded systems with real-time plotting and signal routing techniques
Kit Contents
| Component | Quantity |
|---|---|
| Raspberry Pi Pico 2 | x1 |
| 2.4in TFT ILI9341 | x1 |
| 10kΩ Potentiometer | x2 |
| Tactile Button | x2 |
| 100nF Caps | x5 |
| PCB Prototype Board | x2 |
| ABS Enclosure Box | x1 |
| Micro USB Cable | x1 |
| Soldering Iron | x1 |
| Solder Wire | x1 |
Why Buy This Kit Instead of Sourcing Parts Separately
| Factor | Sourcing Separately | Compoden Kit |
|---|---|---|
| Compatibility checks | You verify every part | Pre-tested as a system |
| Build support | Forums and scattered tutorials | AI companion trained on this exact project |
| Time to first working build | Days of debugging | Hours, with step-by-step guidance |
| Shipping coordination | Multiple sellers, multiple delays | One shipment from Bengaluru in 3-5 days |
Who This Kit Is For
This kit is built for final-year ECE and biomedical engineering students at IIT, NIT, VIT, BITS Pilani, and other top institutions looking for a meaningful capstone project. It’s also ideal for Smart India Hackathon teams exploring healthcare hardware, and for ATL tinkering mentors guiding advanced computational biology workshops.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
The AI companion, accessed via QR code, guides you step-by-step. If you need human help, reach us on WhatsApp and our team will respond within hours.
Do I need prior neuroscience knowledge to build this kit?
A basic understanding of differential equations helps, but the AI companion explains every computational step. You’ll learn the neuroscience as you build.
Can I modify the model to simulate other neuron types?
Absolutely. The open-source MicroPython code on the Pico 2 is fully customizable — swap in the Morris-Lecar or FitzHugh-Nagumo model with a few lines of code.
Is this kit suitable for academic publications or lab demonstrations?
Yes. The Hodgkin-Huxley implementation is faithful to the original equations, and the TFT plotting gives clear visual evidence. Several professors have used our kits for research demos and coursework.
