Radiation Dose Rate Chart Kit – Track & Visualize Environmental Radiation with ESP8266

Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-5 days.

Turn an ESP8266 and a Geiger counter module into a practical environmental radiation monitor. This kit logs counts-per-minute (CPM) to an SD card with precise timestamps and generates hourly dose rate charts along with a monthly cumulative dose summary directly on an OLED display. Whether you’re investigating background radiation for a physics project, building a long-term monitoring device for your locality, or entering a citizen science challenge, you’ll gain hands-on experience in sensor interfacing, data storage, and real‑time visualization.

What You'll Build

You’ll assemble a compact, breadboard‑based radiation logger that reacts to beta and gamma radiation. The OLED shows the current CPM, an hourly dose rate bar chart, and a running total of the month’s accumulated dose. Every reading is saved to a microSD card with an RTC timestamp, so you can later import the CSV into Excel, Python, or cloud platforms. The finished device runs standalone once programmed, giving you a portable instrument for experiments, field trips, or a 24/7 monitoring station at home.

What You'll Learn

• Interfacing a Geiger counter module with an ESP8266 and counting high‑voltage pulses securely
• Logging time‑series sensor data to a microSD card using the DS3231 real‑time clock
• Designing multi‑screen OLED dashboards that update bar charts and cumulative values in real time
• Processing CPM readings into hourly and daily dose rates using simple statistical averaging

Kit Contents

Why Buy This Kit Instead of Sourcing Parts Separately

Who This Kit Is For

This kit fits CBSE Class 11–12 students preparing physics investigatory projects, B.Tech ECE/EEE undergraduates building IoT-based environmental monitors, and teams in Smart India Hackathon or ATL Tinkering Labs. It’s also a solid hands‑on module for hobbyists from IIT, NIT, VIT, and BITS who want to learn data logging, sensor fusion, and real‑time charting on embedded systems.

Built and Backed by Compoden

Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.

Choose your assembly option:

• Soldering Kit — 25W soldering iron, 60/40 solder wire, flux, and small perfboard for permanent assembly.
• Breadboard Combo — 800-point full-size breadboard with 65-piece jumper wire pack for solderless prototyping.
