Soil Temp Kit with Arduino Nano + DS18B20
Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts
Soil Temp Kit with Arduino Nano + DS18B20 — a beginner-level build.
Build a Soil Temperature Monitor with Arduino Nano, a DS18B20 Probe and an OLED Display
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.
Push the waterproof DS18B20 probe into a pot, seed tray or garden bed and read the soil temperature on a small OLED screen. Soil temperature decides when seeds germinate and roots grow, so it is one of the most useful numbers a gardener can watch.
What You'll Build
You wire the DS18B20 probe to an Arduino Nano with a pull-up resistor on its data line, and connect the 0.96 inch OLED over I2C. The sketch reads the probe every few seconds, then shows the current temperature with the day's minimum and maximum on the screen.
What You'll Learn
- Reading a DS18B20 on the 1-Wire bus
- Why the data line needs a pull-up resistor
- Drawing text and numbers on an SSD1306 OLED over I2C
- Tracking minimum and maximum values in code
Kit Contents
| Component | Quantity |
|---|---|
| Arduino Nano (CH340 clone) | 1 |
| DS18B20 Temperature Sensor | 1 |
| 0.96 inch OLED Display Module 128x64 I2C Yellow/Blue (SSD1306) | 1 |
| Resistor Variety Pack - 10 Values, 1/4W Carbon Film | 1 |
| 400-point solderless breadboard | 1 |
| Dupont Jumper Wire Kit (M-M, M-F, F-F, 20cm, 22AWG) | 1 |
Who This Kit Is For
Beginners and gardeners who want a useful first build. It works indoors for seed trays and outdoors with the board kept dry.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
Can the probe stay in wet soil?
Yes, the DS18B20 probe is sealed in a steel tube. Keep the Nano, breadboard and display somewhere dry.
What resistor does the DS18B20 need?
A pull-up resistor of around 4.7 kΩ from the data line to the supply. The kit's resistor pack covers it.
Can I add more probes?
Yes. DS18B20 sensors share one data line, each with its own address, so more probes can join later.
Arduino Nano soil thermometer: a waterproof DS18B20 probe shows the soil temperature, minimum and maximum on an OLED.
What's in this kit
Do you deliver across India?
Yes. We ship Soil Temp Kit with Arduino Nano + DS18B20 across India including Delhi, Mumbai, Bangalore, Hyderabad, Chennai, and Pune. Orders ship in 3-7 days.
What payment options are available for Soil Temp Kit with Arduino Nano + DS18B20?
We accept UPI, all major debit and credit cards, and Cash on Delivery (COD) available.
Built and shipped from Compoden, with UPI and cards, plus COD available.
