Thermal Imaging Sensor Kit Kit with Arduino Uno + Sensor
Build a Real-Time Thermal Camera with Arduino – See Warm Bodies as a Heat Map
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-5 days.
Point this sensor at a person, a pet, or a warm cup, and watch a 64-pixel heat map bloom on the TFT display. The AMG8833 8x8 grid captures infrared radiation, then the Arduino translates those readings into a visible color gradient — colder in blue, hotter in red. It’s a compact practical tool for science fair demonstrations, room occupancy sensing, or studying thermal physics hands-on.
What You'll Build
You’ll assemble a standalone thermal viewer that runs on a breadboard. Power it with a 9V battery, aim the AMG8833 at a scene, and the 1.8-inch color TFT instantly updates a low-resolution heat map. Detect a person walking into the frame, spot insulation leaks in a classroom model, or simply understand how non-contact temperature sensing works — all with code you upload and circuitry you connect yourself.
What You'll Learn
- Interfacing an I2C thermal sensor with Arduino and reading 64-pixel temperature arrays
- Driving a TFT display (ST7735) over SPI to render color-mapped heat maps
- Calibrating sensor data and mapping temperature values to a meaningful color palette
- Troubleshooting signal noise with pull-up resistors and decoupling capacitors on a breadboard
Kit Contents
| Component | Quantity |
|---|---|
| Arduino Uno R3 | 1 |
| AMG8833 Thermal Sensor | 1 |
| 1.8in TFT ST7735 | 1 |
| 4.7kΩ Resistors | 5 |
| 100nF Capacitors | 5 |
| 400-pt Breadboard | 1 |
| Male-Female Jumper Wires | 20 |
| 9V Battery Snap | 1 |
Why Buy This Kit Instead of Sourcing Parts Separately
| Factor | Sourcing Separately | Compoden Kit |
|---|---|---|
| Compatibility checks | You verify every part | Pre-tested as a system |
| Build support | Forums and scattered tutorials | AI companion trained on this exact project |
| Time to first working build | Days of debugging | Hours, with step-by-step guidance |
| Shipping coordination | Multiple sellers, multiple delays | One shipment from Bengaluru in 3-5 days |
Who This Kit Is For
This intermediate kit suits CBSE Class 11–12 students exploring physics or computer science projects, B.Tech ECE/EEE first-years wanting a hands-on sensor lab, and ATL Tinkering Lab mentors guiding thermal experiments. It’s also ideal for Smart India Hackathon teams prototyping body-detection modules or IIT/NIT/VIT makers prepping for campus tech fests.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
Scan the QR code inside the box to start a chat with your AI companion, or send a WhatsApp message with a photo of your circuit. We’ll debug it with you.
Can this thermal camera measure exact body temperature like a medical device?
No, the AMG8833 has an accuracy of ±2.5°C and is designed for relative thermal imaging, not clinical use. It shows hot and cold areas beautifully for learning and detection, but not for fever screening.
Will the 1.8-inch TFT show a clear image of a person across a room?
The 8x8 resolution gives a low-detail heat map, so you’ll see a blob of warm pixels rather than a sharp silhouette. It’s excellent for detecting presence and understanding heat distribution, not for facial recognition.
Do I need a computer to run the thermal camera after building it?
The Arduino runs standalone once you upload the code. Just plug in the 9V battery and the TFT displays the heat map without any laptop connection.
AMG8833 8x8 thermal camera renders a heat map on 1.8in TFT. Detects warm bodies in the frame.
