Wireless Stage Click Track Kit with Arduino Nano + NRF24

SKU: CDN-KIT-0326-CL-SLD Brand: Compoden Category: Electronics > Audio & Music > Project Kits
Rs. 1,060.00
Inclusive of all taxes
Free Shipping on prepaid orders above ₹1,999
Ships in 3-7 days
7-Day Warranty on manufacturing defects
GST invoice 18% GST included · HSN 90230090
Pay with UPI Cards Netbanking Cash on Delivery
Need 10+ units? Contact us for bulk pricing
100% Genuine Products
Expert Technical Support
Quality Tested
Soldr.ai Ask about this product

Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts

Wireless Stage Click Track Kit with Arduino Nano + NRF24 — an advanced-level kit.

Wireless Stage Click Track Kit with Arduino Nano & NRF24L01: Perfect Timing On Stage

Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.

Difficulty: Advanced Build Time: 6-8 hrs Skill: Wireless tempo synchronization

When your band needs a silent click track to lock in the groove, this kit hands you a wireless BPM transmission system you build and program yourself. The master unit lets you dial in a tempo with a knob and broadcasts it via NRF24L01 radios. The receiver slips into a pocket, feeds a sharp click to your earpiece, and flashes an LED on every beat — no cables, no latency, no missed cues during a live set.

What You'll Build

A complete wireless click track system with a master controller that sets BPM through a potentiometer, and a battery-powered receiver that outputs audio through a 3.5mm mono jack and blinks an LED in perfect time. Two Arduino Nanos handle the logic while NRF24L01 modules maintain a stable 2.4 GHz link. The result is a professional-grade stage metronome that keeps drummers, bassists, and entire troupes perfectly synced.

What You'll Learn

  • Programming NRF24L01 modules for low-latency wireless data transfer between two microcontrollers
  • Generating real-time BPM signals and maintaining millisecond-accurate synchronization
  • Designing a clean audio output stage with passive buzzers and filtering capacitors for click tones
  • Soldering, assembling, and packaging a compact battery-operated system for stage use

Kit Contents

Component Quantity
Arduino Nano 2
NRF24L01 2
Passive Buzzer 2
5mm LED Assorted 4
10kΩ Potentiometer 1
100nF Caps 10
10µF Caps 4
PCB Prototype Board 2
3.5mm Mono Jack 2
9V Battery Snap 2
Soldering Iron 1
Solder Wire 1

Who This Kit Is For

B.Tech ECE/EEE students taking on wireless communication projects, college rock band drummers who want a reliable in-ear click track without tethering themselves to a laptop, and Smart India Hackathon teams building music technology

Master Arduino sends BPM clock over NRF24L01. Remote receiver drives earpiece feed and LED flash for live performance.

What's in this kit

Choose your assembly option:

  • Soldering Kit — 25W soldering iron, 60/40 solder wire, flux, and small perfboard for permanent assembly.
  • Breadboard Combo — 800-point full-size breadboard with 65-piece jumper wire pack for solderless prototyping.
