Magnetic Levitation Controller Kit with Arduino Uno - Master PID Control While Levitating a Steel Ball

Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-5 days.

Imagine a iron ball hovering in mid-air, held steady by an invisible force you control. This kit transforms Arduino Uno, a Hall sensor, and an electromagnet into a complete closed-loop levitation system. You'll write a real-time PID algorithm that reads the ball's position 100 times a second and adjusts current to keep it floating - a perfect capstone for control systems coursework, Smart India Hackathon, or a final-year B.Tech project.

What You'll Build

You'll assemble a fully functional magnetic levitator: an electromagnet suspended above a Hall sensor, with a ferromagnetic ball levitating in between. The OLED display shows live position error, current draw, and PID output. Once tuned, the ball floats with sub-millimeter stability, and you can even tap it gently to watch the controller compensate - a mesmerising demonstration of classical control theory in action.

What You'll Learn

• Tune PID constants (proportional, integral, derivative) for stable levitation without oscillation
• Calibrate an A3144 Hall effect sensor and linearise its output to measure sub-millimetre ball displacement
• PWM-drive an IRF540N MOSFET to regulate electromagnet current with an INA219 current sensor for feedback
• Implement sensor fusion and real-time control loops on Arduino Uno with interrupt-driven timing

Kit Contents

Why Buy This Kit Instead of Sourcing Parts Separately

Who This Kit Is For

This advanced kit targets B.Tech and M.Tech students in ECE, EEE, and mechatronics who need a hands-on control system project. It's ideal for Smart India Hackathon teams, IIT/NIT/VIT/BITS lab assignments, and serious hobbyists who have basic Arduino coding experience. If you've already built simpler sensor projects and want to dive deep into feedback loops and automatic control, this is your next challenge.

Built and Backed by Compoden

Every Compoden kit ships with an AI build companion trained on this exact project - accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.

Choose your assembly option:

• Soldering Kit - 25W soldering iron, 60/40 solder wire, flux, and small perfboard for permanent assembly.
• Breadboard Combo - 800-point full-size breadboard with 65-piece jumper wire pack for solderless prototyping.
