CNC Plotter Kit with Arduino Uno & NEMA Stepper Motors
Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts
CNC Plotter Kit with Arduino Uno & NEMA Stepper Motors — an advanced-level kit.
Build a High-Precision CNC Plotter with Arduino Uno & NEMA17 Stepper Motors
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.
Transform your Arduino Uno into a precise 2-axis plotter that reads G-code commands over serial and draws complex vector patterns on paper. This kit equips you with two NEMA17 steppers, an SG90 servo pen lifter, and a CNC Shield V3 to build a desktop pen plotter from scratch-whether for engineering prototypes, PCB art, or custom signage.
What You'll Build
A fully functional CNC pen plotter that takes standard G-code (like those used by laser cutters or 3D printers) and draws with ballpoint or felt-tip pens on A4 paper. You'll create a machine capable of intricate line art, circuit schematics, and even handwritten text, all driven by open-source GRBL firmware running on the Arduino.
What You'll Learn
- Fine-tune A4988 stepper drivers for precise microstepping and current control.
- Parse standard G-code (G0, G1, G2, G3) to convert toolpaths into motor steps.
- Implement servo-controlled pen lift with accurate Z-axis timing.
- Debug motion artifacts and ensure repeatability with homing routines.
Kit Contents
| Component | Quantity |
|---|---|
| Arduino Uno R3 | 1 |
| NEMA 17 Stepper | 2 |
| A4988 Driver | 2 |
| SG90 Servo | 1 |
| CNC Shield V3 | 1 |
| 12V 2A Power Supply | 1 |
| GT2 Belt 1m | 2 |
| GT2 Pulley 20T | 2 |
| Linear Rail 400mm | 2 |
| 100nF Caps | 10 |
| M3 Bolts+Nuts | 20 |
| Soldering Iron | 1 |
| Solder Wire | 1 |
Who This Kit Is For
Tailored for engineering undergraduates (B.Tech in ECE, EEE, or Mechanical) tackling precision motion projects, as well as Smart India Hackathon teams prototyping pen plotters for automated documentation. Also ideal for ATL Tinkering Lab teams ready to move from Arduino basics to CNC-level machinery, and hobbyists seeking a reliable G-code drawing setup without hours of part sourcing.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project - accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What is included in the CNC Plotter Kit with Arduino Uno & NEMA Stepper Motors?
Arduino Uno R3, 2 NEMA 17 stepper motors, 2 A4988 drivers, an SG90 servo for the pen lift, a CNC Shield V3, a 12V 2A power supply, 2 GT2 belts (1 m), 2 GT2 20T pulleys, 2 linear rails (400 mm), 10 100nF capacitors, 20 M3 bolts and nuts, a soldering iron and solder wire. Everything is pre-tested for compatibility and shipped from Bengaluru.
What power supply does the CNC plotter kit use? Is it included?
Yes. The kit includes a 12V 2A power supply for the stepper motors, which it drives through A4988 drivers on the CNC Shield V3.
Does the kit include the GRBL firmware, and is it pre-configured?
The Arduino Uno is not pre-flashed. The AI build companion guides you through uploading a servo-enabled GRBL 1.1 build and setting steps/mm for the GT2 belts. Stock GRBL drives the pen-lift pin as a spindle and can't hold the SG90 servo steady. The servo connects to the Z end-stop header on the CNC Shield and is powered from 5V, not the 12V rail; M3 puts the pen down and M5 lifts it. No extra parts are needed.
What size can it draw, and with what?
The 400 mm linear rails allow a drawing area up to roughly A4 (210 x 297 mm). It reads standard G-code (G0, G1, G2, G3) over serial and draws with ballpoint pens, felt-tip pens or pencils by adjusting the pen holder.
What else do I need?
Paper and pens, and a computer to send G-code to the Arduino over USB.
What skill level is required for the CNC plotter kit?
This kit is designed for advanced makers. Two NEMA 17 steppers drive the X and Y axes and a servo lifts the pen. Estimated build time is 10-12 hours.
What if I get stuck during the build?
Our AI companion, trained on this exact CNC plotter project, provides step-by-step debugging for stepper calibration, belt tensioning, and G-code issues. You can also WhatsApp us for human support.
What if a stepper driver fails or my servo is faulty?
Our 7-day defect replacement policy covers any manufacturing faults. Reach out via WhatsApp with a short video of the issue, and we'll ship a replacement component immediately from Bengaluru.
Do you deliver across India?
Yes. We ship the CNC Plotter Kit with Arduino Uno & NEMA Stepper Motors across India including Delhi, Mumbai, Bangalore, Hyderabad, Chennai, and Pune. Orders ship in 3-7 days.
What payment options are available for the CNC Plotter Kit?
We accept UPI, all major debit and credit cards, and Cash on Delivery (COD) available.
Two NEMA17 steppers drive XY axes and a servo lifts the pen. Draws G-code paths from serial input.
What's in this kit
- Arduino Uno R3
- NEMA 17 Stepper x2
- A4988 Driver x2
- SG90 Servo
- CNC Shield V3
- 12V 2A Power Supply
- GT2 Belt 1m x2
- GT2 Pulley 20T x2
- Linear Rail 400mm x2
- 100nF Caps x10
- M3 Bolts+Nuts x20
- Soldering Iron
- Solder Wire
Built and shipped from Compoden, with UPI and cards, plus COD available.
