Distributed Sensor Fusion Network Kit with ESP32 Mesh and Pi 5 Aggregator

Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-5 days.

Build a distributed sensor network that simulates real-world industrial monitoring. Five ESP32 nodes equipped with motion, temperature, and air-quality sensors communicate over a self-healing mesh network, streaming fused data to a Raspberry Pi 5 aggregator using MQTT. This kit turns a concept into a tangible system for your lab, classroom, or hackathon project.

What You'll Build

A fully functional wireless sensor fusion network where each ESP32 node transmits MPU6050 motion data, DHT22 temperature/humidity, and MQ135 gas concentration readings. The Pi 5 ingests, timestamps, and stores the aggregated data on a high-speed NVMe SSD for real-time dashboards or further analysis.

What You'll Learn

• Configuring an ESP-NOW mesh for node-to-node communication
• Reading and fusing multi-sensor data (IMU, temperature, gas) in real time
• Setting up an MQTT broker on Raspberry Pi 5 and subscribing multiple publishers
• Design

  5 ESP32 nodes form mesh and fuse IMU, temperature and gas sensor data on a Pi 5 aggregator via MQTT.

  What's in this kit

  • ESP32 Dev Board x5
  • MPU6050 IMU x5
  • DHT22 x5
  • MQ135 Gas Sensor x2
  • Raspberry Pi 5 4GB
  • NVMe SSD 128GB
  • Pi 5 M.2 HAT+
  • USB-C PSU
  • MicroUSB Cable x5
  • M-M Wires x30
