Vibration and CO Sensor Kit with Arduino Uno: Two-Sensor Indicator
Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts
Vibration and CO Sensor Kit with Arduino Uno: Two-Sensor Indicator — an intermediate-level kit.
Build a Two-Sensor Indicator with Arduino Uno - Vibration & Carbon Monoxide Sensor Kit
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.
When the ground shakes or invisible carbon monoxide seeps into a room, this kit gives you eyes and ears on the danger. Using an Arduino Uno, you'll build a project that reads a vibration sensor and a CO sensor, sounding a buzzer and switching a relay that drives an LED. It is a learning prototype, not a certified safety device; fit a certified CO alarm.
What You'll Build
You'll assemble a breadboard circuit that reads vibration from a SW-420 sensor and carbon monoxide from an MQ-7. When either reading passes your threshold, red LEDs flash, the buzzer sounds and the relay switches an indicator LED.
What You'll Learn
- Calibrating the MQ-7 gas sensor and interpreting its analog output for CO detection
- Setting adjustable vibration thresholds with the SW-420 and Arduino digital input
- Controlling a 5V relay module from a digital pin
- Combining two sensor inputs in code with independent thresholds
Kit Contents
| Component | Quantity |
|---|---|
| Arduino Uno R3 | 1 |
| SW-420 Vibration Sensor | 1 |
| MQ-7 CO Sensor | 1 |
| 5V Relay Module | 1 |
| Active Buzzer | 1 |
| 5mm Red LED | 3 |
| 1N4007 Diode | 5 |
| 10kΩ Resistor | 5 |
| 220Ω Resistor | 5 |
| 400-pt Breadboard | 1 |
| M-M Wires | 25 |
| 9V Battery Snap | 1 |
Who This Kit Is For
Students preparing for science fairs, first-year B.Tech ECE/EEE learners prototyping for Smart India Hackathon, and ATL Tinkering Lab coordinators running a sensor demo. Anyone exploring multi-sensor projects gets a pre-tested set of parts in one box.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project - accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
Scan the QR code inside the box for immediate AI-guided troubleshooting mapped to each step, or message us on WhatsApp for a human mentor.
Can the relay control a gas valve?
No. Never connect this project to a gas line or gas valve.
SW-420 vibration + MQ-7 CO sensor readings trigger the buzzer and an indicator relay when either passes your threshold.
What's in this kit
- Arduino Uno R3
- SW-420 Vibration Sensor
- MQ-7 CO Sensor
- 5V Relay Module
- Active Buzzer
- 5mm Red LED x3
- 1N4007 Diode x5
- 10kΩ Resistors x5
- 220Ω Resistors x5
- 400-pt Breadboard
- M-M Wires x25
- 9V Battery Snap
