Automatic Staircase Light Kit with Arduino Uno + LDR
Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts
Automatic Staircase Light Kit: Arduino Uno, PIR, LDR, LEDs — a beginner-level kit.
Automatic Staircase Light Kit: Arduino Uno, PIR, LDR, LEDs
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.
Kit at a glance
What you build: An automatic staircase light: two LDRs check it's dark and a PIR spots someone on the stairs, and an Arduino Uno lights five white LEDs for 30 seconds, then switches them off again.
What's in the box
- Arduino Uno R3
- HC-SR501 PIR
- LDR × 2
- 5mm White LED × 5
- 10kΩ Resistors × 10
- 220Ω Resistors × 5
- 400-pt Breadboard
- M-M Wires × 20
- 9V Battery Snap
Power: 9V battery, not included.
Skill level: Beginner (2-3 hours, no soldering).
Frequently asked questions
Why two LDRs?
To average out a single shadow or reflection.
Can it run real stair lamps?
Not as built; it drives LEDs. Add a relay for lamps.
Imagine walking up a dark staircase and seeing the steps light up automatically the moment you approach — then turn themselves off 30 seconds later. That’s exactly what you’ll create with this kit. Using an Arduino Uno, a PIR motion sensor, and two LDR light sensors, you’ll build a hands‑free smart lighting system that conserves energy and makes daily movement safer.
What You'll Build
You’ll assemble a working prototype of an automatic staircase light that switches on only when two conditions are met: the ambient light is low, and someone is moving nearby. The LEDs stay on for exactly 30 seconds, then turn off — perfect for stairways, hallways, or any dark passage in your home.
What You'll Learn
- How PIR sensors detect motion and send signals to a microcontroller
- Using an LDR to measure ambient brightness and trigger actions only in darkness
- Programming the Arduino Uno to read two sensors, control LEDs, and manage timing
- Wiring a complete circuit on a breadboard and powering it with a 9 V battery
Kit Contents
| Component | Quantity |
|---|---|
| Arduino Uno R3 | 1 |
| HC-SR501 PIR | 1 |
| LDR | 2 |
| 5mm White LED | 5 |
| 10kΩ Resistors | 10 |
| 220Ω Resistors | 5 |
| 400-pt Breadboard | 1 |
| M-M Wires | 20 |
| 9V Battery Snap | 1 |
Who This Kit Is For
Good for students exploring electronics in ATL Tinkering Labs, CBSE/ICSE science projects, or anyone who wants to build real-world smart home gadgets. It's also good for STEM at home and for hobbyists taking their first steps with Arduino.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
Scan the QR code on the box to open the AI companion, which walks you through debugging step by step. You can also message us on WhatsApp — a real person will reply within an hour.
Will this kit work outdoors?
The prototype is designed for indoor use. To make it weatherproof for an outdoor staircase, you would need a waterproof enclosure, but the electronics and code remain exactly the same.
Do I need to know coding to build this?
No prior coding experience is required. The kit includes pre‑written Arduino code that you simply upload. The AI companion explains each line so you’ll learn as you build.
Can I power it with a USB charger instead of a 9 V battery?
Yes. The Arduino Uno can run directly from a USB cable or power bank. The included battery snap just gives you the flexibility to place the prototype anywhere.
PIR and LDR auto-switch LEDs on in darkness when motion detected. 30-second auto-off.
What's in this kit
- Arduino Uno R3
- HC-SR501 PIR
- LDR x2
- 5mm White LED x5
- 10kΩ Resistors x10
- 220Ω Resistors x5
- 400-pt Breadboard
- M-M Wires x20
- 9V Battery Snap
