Blind Stick Obstacle Detector Kit with Arduino Nano + HC-SR04

Build an obstacle-sensing add-on for a walking stick. An HC-SR04 ultrasonic sensor watches the path ahead; an Arduino Nano turns the distance into beeps and a vibration in the handle that get faster as an obstacle gets closer.

A learning and prototyping project, not a certified mobility or safety aid. Do not rely on it in place of a cane, guide or trained mobility support.

What's in the kit

  • 1 x Arduino Nano (CH340 clone) (CDN-0049) - the controller (USB cable included for programming)
  • 1 x HC-SR04 Ultrasonic Sensor (CDN-0404) - obstacle distance (2-400 cm)
  • 1 x HC-SR04 Mounting Bracket (CDN-0691) - mounts the sensor facing forward on the stick
  • 1 x Active Buzzer Module 3-5V 85dB (CDN-0850) - beeps faster as an obstacle gets closer
  • 1 x Mini Coin Vibration Motor 10mm 3V (CDN-0914) - vibrates in the handle (silent alert)
  • 1 x BC547 NPN Transistor (CDN-0896) - switches the vibration motor (a pin cannot drive it directly)
  • 1 x Resistor Variety Pack - , 10 Values, 1/4W Carbon Film (CDN-0834) - 1kΩ transistor base resistor
  • 1 x Diode Variety Pack (1N4007, 1N4148, 1N5819, Zener Assortment) (CDN-0844) - 1N4148 flyback diode across the motor
  • 1 x 2 x 18650 Battery Holder With ON/OFF Switch Case (CDN-2032) - power + the ON/OFF switch (7.4 V into the Nano VIN)
  • 2 x 18650 Li-ion Battery 2600mAh (CDN-0851) - the two cells for the holder
  • 1 x Dupont Jumper Wire Kit (M-M, M-F, F-F, 20cm, 22AWG, ) (CDN-0791) - wiring
  • 1 x Perfboard 9x15cm 2.54mm (CDN-0954) - solder the transistor + diode into a small board on the stick

Not included: An 18650 charger and the stick itself (any walking stick / PVC pipe).

How it works

  • HC-SR04: VCC 5V, GND, TRIG D9, ECHO D10. Buzzer module: VCC 5V, GND, I/O D6.
  • Vibration motor: Nano 5V -> motor -> BC547 collector; emitter to GND; base via 1kΩ from D5; 1N4148 across the motor (stripe to 5V). Drive D5 with ~60% PWM so the 3 V motor sees ~3 V average.
  • Power: the 2 x 18650 holder (switch OFF while wiring) red -> Nano VIN, black -> GND. Charge the cells in an 18650 charger, never unattended.
  • Alert: under ~100 cm the buzzer beeps and the motor pulses, faster as the obstacle gets closer; continuous under ~30 cm.

Want the full wiring and code? Open this kit in Soldr and it walks you through the build.
