Wrist Pulse + Motion Logger Kit: Pi Zero W, MAX30102
Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts
Wrist Pulse + Motion Logger Kit: Pi Zero W, MAX30102 — an advanced-level kit.
Wrist Pulse + Motion Logger Kit: Pi Zero W, MAX30102
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 15-25 days.
This is a learning project, not a medical device. Don't use it to diagnose, treat or monitor any health condition.
What You'll Learn
- Interfacing I2C sensors (MPU6050 and MAX30102) with Raspberry Pi Zero W
- Logging sensor data to CSV files on an SD card using Python
- Designing a portable battery-powered wearable circuit with LiPo and TP4056 charger
- Writing interrupt-driven step counting algorithms using accelerometer data
Kit Contents
| Component | Quantity |
|---|---|
| Raspberry Pi Zero W | 1 |
| MAX30102 | 1 |
| MPU6050 | 1 |
| 0.96in OLED | 1 |
| TP4056 Module | 1 |
| 3.7V LiPo 1000mAh | 1 |
| 4.7kΩ Resistors | 5 |
| 40-pin GPIO Header | 1 |
| M-F Wires | 20 |
| MicroSD Card 16GB | 1 |
| Velcro Strap | 1 |
| Soldering Iron | 1 |
| Solder Wire | 1 |
Who This Kit Is For
Ideal for those in IIT, NIT, VIT, BITS, or ATL Tinkering Labs advancing to complex sensor integration.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
Scan the QR code to launch the AI build companion trained specifically for this step counter kit, or message us on WhatsApp for direct troubleshooting.
Does this kit require soldering?
Yes, the 40-pin GPIO header must be soldered to the Pi Zero W, and sensor connections are soldered. A soldering iron and solder wire are included.
Can I view the data on my phone?
Logged CSV files on the MicroSD card can be transferred to a computer or phone via a card reader for analysis.
Is the battery rechargeable?
Yes, the included 3.7V 1000mAh LiPo is recharged via the TP4056 module with any micro USB cable.
