Colour Detector Kit: Arduino Uno, TCS3200, RGB LEDs
Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts
Colour Detector Kit: Arduino Uno, TCS3200, RGB LEDs — a beginner-level kit.
Colour Detector Kit: Arduino Uno, TCS3200, RGB LEDs
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.
Kit at a glance
What you build: A colour detector: a TCS3200 sensor reads an object's colour, and an Arduino Uno lights the matching red, green or blue LED. It's the sensing half of a colour sorter, including the calibration you'd reuse in a sorting machine.
What's in the box
- Arduino Uno R3
- TCS3200 Color Sensor
- 5mm Red LED × 2
- 5mm Green LED × 2
- 5mm Blue LED × 2
- 220Ω Resistors × 10
- 10kΩ Resistors × 5
- 400-pt Breadboard
- M-M Wires × 20
- 9V Battery Snap
Power: 9V battery, not included.
Skill level: Beginner (2-3 hours, no soldering).
Frequently asked questions
Does it physically sort objects?
No. There's no servo or conveyor; it identifies colours.
Why calibrate?
The sensor reads differently under each light, so you record white and black first.
Using a TCS3200 colour sensor and an Arduino Uno, you’ll build a circuit that instantly identifies whether an object is red, green, or blue and lights up the matching LED. No soldering, no complex code; everything connects on a breadboard in a few focused hours.
What You'll Learn
- How a colour sensor measures RGB values and outputs frequency to a microcontroller
- Wiring and reading sensor data with an Arduino Uno using digital pins
- Writing if-else logical conditions to map colour ranges to specific LEDs
- Debugging real circuits on a 400-point breadboard and interpreting serial output
Kit Contents
| Component | Quantity |
|---|---|
| Arduino Uno R3 | 1 |
| TCS3200 Color Sensor | 1 |
| 5mm Red LED | 2 |
| 5mm Green LED | 2 |
| 5mm Blue LED | 2 |
| 220Ω Resistors | 10 |
| 10kΩ Resistors | 5 |
| 400-pt Breadboard | 1 |
| M-M Wires | 20 |
| 9V Battery Snap | 1 |
LED displays matching colour.
What's in this kit
- Arduino Uno R3
- TCS3200 Color Sensor
- 5mm Red LED x2
- 5mm Green LED x2
- 5mm Blue LED x2
- 220Ω Resistors x10
- 10kΩ Resistors x5
- 400-pt Breadboard
- M-M Wires x20
- 9V Battery Snap
