Respiration Rate and Depth Monitor Kit with Arduino Nano + MPU6050
Build a Respiration Rate and Depth Monitor for Sleep Studies — Arduino Nano Kit
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-5 days.
This kit enables you to construct a wearable respiration monitor that tracks breathing rate, depth, and patterns by fusing data from force-sensitive resistors integrated into a chest strap and a precision MPU6050 inertial sensor. All readings are time-stamped by a real-time clock and saved to a microSD card, creating a detailed record for sleep studies, clinical observation, or personal health tracking.
What You'll Build
You'll assemble a compact, battery-powered device worn around the chest. It detects inhalation and exhalation via two FSR 402 sensors that measure strap expansion and contraction, while the MPU6050 captures chest orientation and subtle movement artifacts. The system displays real-time respiration rate on an OLED screen and logs full session data to an SD card for later analysis. The result is a research-grade logger that you can use overnight or during respiratory exercises.
What You'll Learn
- Calibrating FSR sensors for chest strain measurement to extract breathing waveforms
- Fusing IMU data with resistive sensor signals to improve breathing pattern accuracy and remove motion artifacts
- Implementing SD card data logging with DS3231 real-time clock timestamps for precise event marking
- Building a low-power wearable system with LiPo battery and TP4056 charging circuit for extended use
Kit Contents
| Component | Quantity |
|---|---|
| Arduino Nano | 1 |
| FSR 402 | 2 |
| MPU6050 | 1 |
| DS3231 RTC | 1 |
| MicroSD Module | 1 |
| 0.96in OLED | 1 |
| 10kΩ Resistors | 5 |
| 100nF Capacitors | 5 |
| PCB Prototype Board | 2 |
| 3.7V LiPo 500mAh | 1 |
| TP4056 Module | 1 |
| Elastic Strap 60cm | 1 |
| Soldering Iron | 1 |
| Solder Wire | 1 |
Why Buy This Kit Instead of Sourcing Parts Separately
| Factor | Sourcing Separately | Compoden Kit |
|---|---|---|
| Compatibility checks | You verify every part | Pre-tested as a system |
| Build support | Forums and scattered tutorials | AI companion trained on this exact project |
| Time to first working build | Days of debugging | Hours, with step-by-step guidance |
| Shipping coordination | Multiple sellers, multiple delays | One shipment from Bengaluru in 3-5 days |
Who This Kit Is For
This kit is designed for engineering students in ECE, EEE, or Biomedical streams working on health monitoring prototypes for college projects, hackathons like Smart India Hackathon, or personal research. It is ideal for B.Tech final-year projects at IITs, NITs, VIT, or BITS Pilani
FSR chest strap + MPU6050 combined measure breathing rate, depth and pattern. Logs to SD for sleep study.
What's in this kit
- Arduino Nano
- FSR 402 x2
- MPU6050
- DS3231 RTC
- MicroSD Module
- 0.96in OLED
- 10kΩ Resistors x5
- 100nF Caps x5
- PCB Prototype Board x2
- 3.7V LiPo 500mAh
- TP4056 Module
- Elastic Strap 60cm
- Soldering Iron
- Solder Wire
Choose your assembly option:
- Soldering Kit — 25W soldering iron, 60/40 solder wire, flux, and small perfboard for permanent assembly.
- Breadboard Combo — 800-point full-size breadboard with 65-piece jumper wire pack for solderless prototyping.
