Multi-Room Call Button Kit: Arduino Uno, 3 Buttons, LCD
Open this project in the Soldr app → What is Soldr.ai → wiring, code and test steps for exactly these parts
Multi-Room Call Button Kit: Arduino Uno, 3 Buttons, LCD — a beginner-level kit.
Multi-Room Call Button Kit: Arduino Uno, 3 Buttons, LCD
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-7 days.
Kit at a glance
What you build: A multi-room call button: a button in each of three rooms rings one shared buzzer, and an Arduino Uno shows which room called on a 16x2 LCD, so family members can call each other around the house.
What's in the box
- Arduino Uno R3
- Tactile Button × 3
- Active Buzzer
- 16x2 LCD
- I2C Backpack
- 10kΩ Resistors × 5
- 220Ω Resistors × 5
- 400-pt Breadboard
- M-M Wires × 20
- 9V Battery Snap
Power: 9V battery, not included.
Skill level: Beginner (2-3 hours, no soldering).
Frequently asked questions
Is it a medical or emergency alert?
No. It's a household call button for learning.
Is it wireless?
No. Buttons are wired to the Uno.
Imagine a single buzzer that alerts you exactly which room needs attention – just like a nurse call system, but built with your own hands. This kit puts that idea on your workbench: three pushbuttons located in different rooms, one shared active buzzer, and a 16×2 LCD screen that instantly shows “Bedroom,” “Kitchen,” or “Living Room” when a button is pressed. It’s a practical introduction to home automation, perfectly sized for a bedroom-to-living-room experiment or a school technology demonstration.
What You'll Build
You’ll assemble a three-zone alert system on a single breadboard. Each tactile button represents a room; pressing any one immediately activates the buzzer and displays a custom message on the LCD. The wiring uses pull-down resistors for stable readings, and the I2C backpack simplifies the LCD connection to just four wires. When finished, you’ll have a working prototype that can be mounted in a cardboard house model or expanded with longer wires for real inter-room testing.
What You'll Learn
- Solderless breadboard prototyping with real components
- Reading multiple digital inputs from tactile buttons with pull-down resistors
- Programming the Arduino Uno to detect which button was pressed and trigger outputs accordingly
- Controlling a 16×2 LCD via I2C to display dynamic room names
Kit Contents
| Component | Quantity |
|---|---|
| Arduino Uno R3 | x1 |
| Tactile Button | x3 |
| Active Buzzer | x1 |
| 16x2 LCD | x1 |
| I2C Backpack | x1 |
| 10kΩ Resistors | x5 |
| 220Ω Resistors | x5 |
| 400-pt Breadboard | x1 |
| M-M Wires | x20 |
| 9V Battery Snap | x1 |
Who This Kit Is For
This kit fits ATL Tinkering Labs, CBSE science activity periods and school electronics clubs. It also serves first-year B.Tech ECE students at IIT, NIT, VIT, or BITS who need a tangible demo of input/output programming. Hobbyists looking for a weekend home-automation project will appreciate the guided build.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project — accessible via a QR code on the box, with WhatsApp and email backup. We’ve spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
Scan the QR code on the box to chat with our AI build companion, trained on this exact multi-room alarm project. You can also reach us on WhatsApp for human support.
Can I add more than three rooms?
Absolutely. The Arduino Uno has several unused digital pins. You can expand the circuit with extra buttons and modify the code to display additional room names — a great way to extend the learning.
Does the kit include a battery?
The kit includes a 9V battery snap so you can power the Arduino on the go. A 9V battery is not included due to shipping restrictions, but any standard 9V battery works perfectly.
Button in each of three rooms triggers shared buzzer and shows which room on LCD.
What's in this kit
- Arduino Uno R3
- Tactile Button x3
- Active Buzzer
- 16x2 LCD
- I2C Backpack
- 10kΩ Resistors x5
- 220Ω Resistors x5
- 400-pt Breadboard
- M-M Wires x20
- 9V Battery Snap
Do you deliver across India?
Yes. We ship Multi-Room Call Button Kit: Arduino Uno, 3 Buttons, LCD across India including Delhi, Mumbai, Bangalore, Hyderabad, Chennai, and Pune. Orders ship in 3-7 days.
What payment options are available for Multi-Room Call Button Kit: Arduino Uno, 3 Buttons, LCD?
We accept UPI, all major debit and credit cards, and Cash on Delivery (COD) available.
Built and shipped from Compoden, with UPI and cards, plus COD available.
