WiFi 6 vs WiFi 4 Benchmark Kit - ESP32-C6 Throughput Test with OLED
WiFi 6 Throughput Benchmark Kit - ESP32-C6 vs ESP32 Live OLED Comparison
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-5 days.
This kit places two generations of Wi-Fi silicon side by side-ESP32 (WiFi 4) and ESP32-C6 (WiFi 6)-and lets you measure raw TCP/UDP throughput at identical distances. Two OLED panels plot Mbps in real time as you walk the boards apart, turning a lab bench into a visible propagation-loss experiment. For final-year ECE/EEE students, network-engineering minors, and IoT performance teams, the build replaces guesswork with numbers.
What You'll Build
You'll assemble two identical measurement nodes, each housing an ESP board, an OLED display, and stable 5V regulation. One node becomes the reference WiFi 4 endpoint; the other carries the WiFi 6 radio. When both are flashed with our benchmark firmware and placed at the same location, you can move the receiver progressively farther away and watch the Mbps trend lines diverge on the twin OLEDs. At the end you have a calibrated, repeatable testbed that produces publishable throughput-vs-distance data-ideal for a capstone report, a conference demo, or a Smart India Hackathon prototype validation.
What You'll Learn
- Configure ESP32 and ESP32-C6 station-AP links and extract PHY-rate statistics
- Implement a packet-burst throughput test loop that drives both radios simultaneously
- Drive 0.96-in I�C OLEDs to plot real-time Mbps curves using the SSD1306 library
- Analyze throughput degradation over distance, isolating WiFi 6 OFDMA and TWT advantages in a controlled setup
Kit Contents
| Component | Quantity |
|---|---|
| ESP32-C6 Dev Board | 1 |
| ESP32 Dev Board | 1 |
| 0.96in OLED | 2 |
| 4.7k? Resistors | 5 |
| 100nF Capacitors | 5 |
| PCB Prototype Board | 2 |
| 5V 2A PSU | 2 |
| Enclosure Box | 2 |
| Soldering Iron | 1 |
| Solder Wire | 1 |
Why Buy This Kit Instead of Sourcing Parts Separately
| Factor | Sourcing Separately | Compoden Kit |
|---|---|---|
| Compatibility checks | You verify every part | Pre-tested as a system |
| Build support | Forums and scattered tutorials | AI companion trained on this exact project |
| Time to first working build | Days of debugging | Hours, with step-by-step guidance |
| Shipping coordination | Multiple sellers, multiple delays | One shipment from Bengaluru in 3-5 days |
Who This Kit Is For
This build is designed for B.Tech ECE/EEE students final-year project groups who need a quantitative network performance chapter, as well as M.Tech communication-systems candidates running lab experiments on OFDMA gain. It also fits Smart India Hackathon teams that must demonstrate a connectivity advantage in their IoT solutions, ATL Tinkering Lab mentors guiding advanced prototyping, and faculty at IIT, NIT, VIT, or BITS setting up a wireless benchmarking station for a communication lab.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project - accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
Scan the QR code inside the box to open the AI companion trained on this kit; it can walk you through wiring, firmware upload, and troubleshooting. You can also reach our support team on WhatsApp for a direct conversation.
How do I ensure distance measurements are accurate for the throughput-vs-distance plot?
The kit includes instructions to use a measuring tape or laser rangefinder. The AI companion explains how to take readings at fixed intervals (e.g., every 2 metres) and record the OLED-displayed Mbps values for each board simultaneously.
The OLED occasionally flickers or shows incorrect values. What is the likely cause?
Flickering is most often a power-supply ripple issue. Double-check that the 100nF capacitors are soldered close to the OLED VCC pin, and confirm both 5V PSUs are delivering stable voltage under load. The AI companion provides a step-by-step check.
Can I extend this experiment to test UDP jitter and packet loss alongside throughput?
Yes. The firmware is open-source and modifiable. The AI companion includes pointers to add a jitter calculation loop using timestamps on the receiving side, and you can display extra metrics on the second OLED's remaining screen area.
ESP32-C6 WiFi 6 throughput vs ESP32 WiFi 4 measured over same distance. OLED plots Mbps comparison.
