Arduino Sleep Stage Tracker Kit: MPU6050 + MAX30102
Arduino Nano Sleep Stage Tracker with MPU6050 & MAX30102
Every part needed, pre-tested for compatibility, with an AI build companion trained on this exact project. Shipped from Bengaluru in 3-5 days.
For coaches and serious athletes, tracking overnight sleep architecture is the missing piece in recovery optimisation. This kit lets you build a wrist-worn logger that fuses 6-axis motion from an MPU6050 with photoplethysmography (PPG) heart-rate signals from a MAX30102, then runs a custom algorithm to pull out REM, light, and deep sleep phases from an entire night's data. Instead of guessing sleep quality, you get a minute-by-minute sleep-stage timeline you can correlate with training load, diet, and competition schedules.
What You'll Build
A rechargeable, wearable band that records raw inertial and optical biosensor data to a MicroSD card while you sleep. After waking, you transfer the log file to a laptop and run a Python pipeline that computes movement intensity, heart-rate variability features, and body-orientation patterns. The output is a CSV-style hypnogram marking each epoch as REM, light, or deep sleep - a compact research-grade concept scaled to a DIY wristband.
What You'll Learn
- Simultaneous interfacing of an MPU6050 IMU and a MAX30102 PPG sensor on a single I�C bus with Arduino Nano
- Designing a battery-operated, low-power data-logging system using a DS3231 RTC and TP4056 charger
- Extracting motion and heart-rate variability features relevant to sleep staging
- Implementing a multi-sensor fusion algorithm to classify sleep states in Python, and validating results against standard actigraphy principles
Kit Contents
| Component | Quantity |
|---|---|
| Arduino Nano | 1 |
| MPU6050 | 1 |
| MAX30102 | 1 |
| DS3231 RTC | 1 |
| MicroSD Module | 1 |
| 0.96in OLED | 1 |
| 4.7k? Resistors | 5 |
| 100nF Caps | 10 |
| 3.7V LiPo 500mAh | 1 |
| TP4056 Module | 1 |
| PCB Prototype Board | 2 |
| Velcro Wristband | 1 |
| Soldering Iron | 1 |
| Solder Wire | 1 |
Why Buy This Kit Instead of Sourcing Parts Separately
| Factor | Sourcing Separately | Compoden Kit |
|---|---|---|
| Compatibility checks | You verify every part | Pre-tested as a system |
| Build support | Forums and scattered tutorials | AI companion trained on this exact project |
| Time to first working build | Days of debugging | Hours, with step-by-step guidance |
| Shipping coordination | Multiple sellers, multiple delays | One shipment from Bengaluru in 3-5 days |
Who This Kit Is For
This advanced kit is ideal for B.Tech ECE/EEE students building final-year projects in biomedical wearables, teams competing in Smart India Hackathon who need a validated sleep-tracking prototype, and students at IITs, NITs, VIT, or BITS Pilani who want to explore sensor fusion and health IoT. It also suits coaches and sports science enthusiasts who can script data analysis and want a hands-on tool for athlete recovery monitoring.
Built and Backed by Compoden
Every Compoden kit ships with an AI build companion trained on this exact project - accessible via a QR code on the box, with WhatsApp and email backup. We've spent 10 years building projects for makers, schools, and institutions across India. If a part fails because of a manufacturing defect, replace it free within 7 days.
What if I get stuck during the build?
Scan the QR code inside the box to chat with an AI companion trained on the Sport Form Coach Pro wiring and code. If you need human help, WhatsApp support is included - our engineers respond within a few hours.
Will this kit give me clinical-grade sleep staging?
No, it's an educational project that demonstrates the principles of actigraphy and PPG-based sleep monitoring. The algorithm provides approximate classifications suitable for learning, personal insights, and engineering demonstration - not medical diagnosis.
Do I need advanced programming skills?
Yes. You'll modify and upload Arduino sensor-fusion code, then run a provided Python script to process the logged data. The AI companion explains every block, but familiarity with C/C++ and Python is assumed.
Is soldering necessary?
Absolutely. The kit includes a soldering iron and solder wire, and you will assemble all components on the PCB protoboards to create a compact, wearable circuit that fits inside the wristband pouch.
Sports - MPU6050 wrist motion + MAX30102 BPM combine to estimate REM, light and deep sleep stages overnight.
What's in this kit
Choose your assembly option:
- Soldering Kit - 25W soldering iron, 60/40 solder wire, flux, and small perfboard for permanent assembly.
- Breadboard Combo - 800-point full-size breadboard with 65-piece jumper wire pack for solderless prototyping.
